mpn:
brand:
manufacturer:
MPN:
Weight:
87.0
Weight:
5.4375 LB
Min Offer Price:
394.09
Price:
555.23
qty:
21
simpleSku:
ODEwOA:::36VF28
sku:
ODEwOA::GW:36VF28@y0
condition:
11
seller:
Zoro
amzMan:
cai - dayton
DropShip:
True
Dimensions:
[21.0, 17.0, 14.0]
Attributes
| Key | Value |
|---|---|
| Amps | 8.4-7.6/3.8 |
| Bearings | Ball |
| Brand | Dayton |
| CC Number | CC029A |
| Current Stock | 42 |
| Duty Cycle | Continuous |
| Efficiency | 89.5% |
| Enclosure Material | Steel |
| Enclosure Type | TEFC (Totally Enclosed Fan Cooled) |
| Environmental Claim | None |
| Frame | 182/4T |
| Full Load Amps | 7.6/3.8 |
| Green Certification or Other Recognition | NEMA Premium(R) Rated |
| Green Environmental Attribute | Product Contributes To Reducing Energy Consumption |
| HP | 3 |
| Hz | 60 |
| Includes | Conduit Box |
| Ins. Class | F |
| Insulation Class | F |
| International Shipping | No |
| Inverter Rated | Yes |
| Item | General Purpose Motor |
| Length Less Shaft | 15 3/16 in |
| Manufacturers Warranty Length | 1 yr |
| Max. Ambient Temp. | 40 Degrees C |
| Maximum Ambient Temperature | 40? C |
| Motor Application | General Application |
| Motor Bearings | Ball |
| Motor Design | 3-Phase |
| Motor Efficiency Group | NEMA Premium Efficient |
| Motor Enclosure Design | Totally Enclosed Fan-Cooled |
| Motor Frame Material | Rolled Steel |
| Motor Mounting Position | Horizontal |
| Motor Mounting Type | Rigid Base |
| Motor Service Factor | 1.15 |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | CW/CCW |
| Motor Shell Length | 15-5/32" |
| Motor Thermal Protection | None, Not Applicable |
| Mounting | Rigid |
| Mpn | 36VF28 |
| Nameplate RPM | 1,765 |
| No. of Speeds | 1 |
| Nominal Efficiency | 89.5 % |
| Number of Speeds | 1 |
| Overall Length | 17-15/16", 17 15/16 in |
| Phase | 3, Three |
| Product Type | 3 Phase |
| Rotation | Reversible |
| RPM | 1765 |
| RPM Range | 1,701-1,800 |
| Service Factor (SF) | 1.15 |
| Shaft Dia. | 1 1/8 in |
| Shaft Diameter | 1-1/8" Keyed |
| Shaft Length | 2-3/4", 2 3/4 in |
| Ship Weight | 87 lbs. |
| SKU | ZO-G0692207 |
| Standards | CE, CSA, UL Recognized (E47479) |
| SubCategory | Motors/Ac Motors |
| Thermal Protection | None |
| UPC | 190735275603 |
| Voltage | 208-230/460V AC |
| Voltage Compatibility | 200-230/440V AC, 200-230/460V AC, 208-230/460V AC, 460V AC |
| Volts | 208-230/460 |
All Prices
| Img | Seller | Supplier SKU | Requested Price | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
 | Zoro | G0692207 | 555.23 | 555.23 | 1 | 186 | Dayton | 86.8 | 555.23 @ Qty: 1+ | |
 | simsupply.com | ZO-G0692207 | 644.13 | 644.13 | 1 | 42 | Dayton | 644.13 @ Qty: 1+ | ||
| grainger.ca | WWG36VF28 | 650.7939499 | 650.7939499 | 1 | In Stock | DAYTON | 86.8 | 650.7939499 @ Qty: 1+ | ||
| emotorpro.com | 36VF28 | 676.48 | 676.48 | 1 | In Stock | Dayton | 87.0 | 676.48 @ Qty: 1+ | ||
 | sustainablesupply.com | C2611239 | 695.24 | 695.24 | 1 | In Stock | Dayton | 86.8 | 695.24 @ Qty: 1+ | |
 | Raptor Supplies | AH7KMR | 857.3538285 | 857.3538285 | 1 | In Stock | DAYTON | 857.3538285 @ Qty: 1+ |
