mpn:
brand:
manufacturer:
MPN:
Weight:
6.3125
Weight:
6.3125 LB
Price:
476.48
qty:
21
simpleSku:
ODEwOA:::36VF38
sku:
ODEwOA::6Z:36VF38@y0
condition:
11
seller:
AmazonSC
amzMan:
cai - dayton
DropShip:
True
Dimensions:
[21.0, 17.0, 13.0]
Attributes
| Key | Value |
|---|---|
| Amps | 14.0-12.7/6.3 |
| Bearings | Ball |
| Brand | Dayton |
| CC Number | CC029A |
| Current Stock | 42 |
| Duty Cycle | Continuous |
| Efficiency | 89.5% |
| Enclosure Material | Steel |
| Enclosure Type | ODP (Open Dripproof) |
| Environmental Claim | None |
| Frame | 182/4T |
| Full Load Amps | 12.7/6.3 |
| Green Certification or Other Recognition | NEMA Premium(R) Rated |
| Green Environmental Attribute | Product Contributes To Reducing Energy Consumption |
| HP | 5 |
| Hz | 60 |
| Includes | Conduit Box |
| Ins. Class | F |
| Insulation Class | F |
| International Shipping | No |
| Inverter Rated | Yes |
| Item | General Purpose Motor |
| Length Less Shaft | 13 5/8 in |
| Manufacturers Warranty Length | 1 yr |
| Max. Ambient Temp. | 40 Degrees C |
| Maximum Ambient Temperature | 40? C |
| Motor Application | General Application |
| Motor Bearings | Ball |
| Motor Design | 3-Phase |
| Motor Efficiency Group | NEMA Premium Efficient |
| Motor Enclosure Design | Open Dripproof |
| Motor Frame Material | Rolled Steel |
| Motor Mounting Position | Horizontal |
| Motor Mounting Type | Rigid Base |
| Motor Service Factor | 1.15 |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | CW/CCW |
| Motor Shell Length | 13-19/32" |
| Motor Thermal Protection | None, Not Applicable |
| Mounting | Rigid |
| Mpn | 36VF38 |
| Nameplate RPM | 1,760 |
| No. of Speeds | 1 |
| Nominal Efficiency | 89.5 % |
| Number of Speeds | 1 |
| Overall Length | 16 3/8 in, 16-3/8" |
| Phase | 3, Three |
| Product Type | 3 Phase |
| Rotation | Reversible |
| RPM | 1760 |
| RPM Range | 1,701-1,800 |
| Service Factor (SF) | 1.15 |
| Shaft Dia. | 1 1/8 in |
| Shaft Diameter | 1-1/8" Keyed |
| Shaft Length | 2-3/4", 2 3/4 in |
| Ship Weight | 75 lbs. |
| SKU | ZO-G1578641 |
| Standards | CE, CSA, UL |
| SubCategory | Motors/Ac Motors |
| Thermal Protection | None |
| UPC | 190735275702 |
| Voltage | 230/460V AC |
| Voltage Compatibility | 200-230/440V AC, 200-230/460V AC, 208-220/440V AC, 208-230/460V AC, 230/460V AC |
| Volts | 208-230/460 |
All Prices
| Img | Seller | Supplier SKU | Requested Price | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
| AmazonSC | B01LYUNQS9 | 476.48 | 476.48 | 1 | In Stock | Dayton | 476.48 @ Qty: 1+ | |||
| AmazonTP | B01LYUNQS9 | 498.78 | 498.78 | 1 | In Stock | 10 | DAYTON | 498.78 @ Qty: 1+ | ||
| grainger.ca | WWG36VF38 | 691.77295666 | 691.77295666 | 1 | In Stock | DAYTON | 88.2 | 691.77295666 @ Qty: 1+ | ||
 | Zoro | G1578641 | 752.99 | 752.99 | 1 | 254 | Dayton | 88.2 | 752.99 @ Qty: 1+ | |
 | simsupply.com | ZO-G1578641 | 873.31 | 873.31 | 1 | 42 | Dayton | 873.31 @ Qty: 1+ | ||
| emotorpro.com | 36VF38 | 879.76 | 879.76 | 1 | In Stock | Dayton | 75.0 | 879.76 @ Qty: 1+ | ||
 | sustainablesupply.com | C2979915 | 1003.08 | 1003.08 | 1 | In Stock | Dayton | 101.0 | 1003.08 @ Qty: 1+ | |
 | Raptor Supplies | AH7KNC | 1157.976846 | 1157.976846 | 1 | In Stock | DAYTON | 1157.976846 @ Qty: 1+ |
