mpn:
brand:
manufacturer:
MPN:
Weight:
18.0
Weight:
1.1875 LB
Preferred Price:
266.42
Price:
266.42
Min Simple Price:
150.61
Absolute Min Price:
213.71
Min Price:
213.71
Dimensions:
[16.0, 11.0, 9.0]
qty:
21
simpleSku:
ODEwOA:::4K252
sku:
ODEwOA::59:4K252@y0
condition:
11
seller:
AmazonTP
amzMan:
cai - dayton
HazMat:
False
DropShip:
True
Attributes
| Key ^ | Value |
|---|---|
| Amps, Full Load Amps | 6.6/3.1-3.3 |
| Bearings, Motor Bearings | Ball |
| Body Dia. | 5 5/8 in |
| Brand | Dayton |
| Country of Origin (subject to change) | Multiple |
| Cross Reference | 6K778, 4UE63, 4K259, 6K570 |
| Current Stock | 42 |
| Duty, Duty Cycle | Continuous |
| Efficiency | 56.4% |
| Enclosure Material, Frame Material | Steel |
| Enclosure Type | ODP (Open Dripproof) |
| Frame | 48YZ |
| HP | 1/3 |
| Hz | 60 |
| Ins. Class, Insulation Class | B |
| International Shipping | No |
| Item | Belt Drive Motor |
| Length Less Shaft | 8 3/8 in |
| Max. Ambient Temp. | 40 Degrees C |
| Maximum Ambient Temperature | 40? C |
| Motor Application | HVAC/R |
| Motor Design | Split-Phase |
| Motor Diameter | 5-5/8" |
| Motor Enclosure Design | Open Dripproof |
| Motor Frame Material | Rolled Steel |
| Motor Mounting Position | All Angle |
| Motor Mounting Type | Cradle Base |
| Motor Service Factor, Service Factor (SF) | 1.35 |
| Motor Shaft Design | Flat |
| Motor Shaft Rotation | CW/CCW |
| Motor Shell Length | 8-3/8" |
| Motor Sub Application | Belt Drive Fan/Blower |
| Motor Thermal Protection | Auto |
| Mounting | Cradle |
| Mpn | 4K252 |
| Nameplate RPM | 1,725 |
| No. of Speeds, Number of Speeds, Phase | 1 |
| Nominal Efficiency | 56.4 % |
| Overall Length | 10-1/4", 10 1/4 in |
| Phase | Single |
| Product Type | Split Phase |
| Resilient Ring Dia. | 2 1/2 in |
| Ring to Ring Center | 8 1/16 in |
| Rotation | Reversible |
| RPM | 1725 |
| RPM Range | 1,701-1,800 |
| Shaft Dia. | 1/2 in |
| Shaft Diameter | 1/2" Flatted |
| Shaft Length | 1-7/8", 1 7/8 in |
| Ship Weight | 18 lbs. |
| SKU | ZO-G3466111 |
| Standards | CSA Certified (258501), UL Recognized (E37403) |
| SubCategory | Motors/Ac Motors |
| Thermal Protection | Automatic |
| UPC | 190735327500 |
| Voltage | 115/208-230V AC |
| Voltage Compatibility | 115/200-230V AC, 115/208-230V AC, 115V AC, 208-230V AC |
| Volts | 115/208-230 |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
| AmazonTP | B001GBML4A | 150.61 | 150.61 | 1 | In Stock | 2 | DAYTON | 150.61 @ Qty: 1+ | ||
 | Zoro | G3466111 | 166.02 | 166.02 | 1 | In Stock | Dayton | 19.0 | 166.02 @ Qty: 1+ | |
 | simsupply.com | ZO-G3466111 | 188.69 | 188.69 | 1 | 42 | Dayton | 188.69 @ Qty: 1+ | ||
| emotorpro.com | 4K252 | 236.77 | 236.77 | 1 | In Stock | Dayton | 18.0 | 236.77 @ Qty: 1+ | ||
 | sustainablesupply.com | C1560660 | 240.66 | 240.66 | 1 | In Stock | Dayton | 17.99 | 240.66 @ Qty: 1+ | |
 | Raptor Supplies | AD8FWF | 296.7793335 | 296.7793335 | 1 | In Stock | DAYTON | 296.7793335 @ Qty: 1+ |
