DIXON 2HTF2 - MROSupply.com
Weight:
0.31
Weight:
0.019375 LB
Preferred Price:
394.97
Price:
394.97
Min Simple Price:
44.63
Absolute Min Price:
316.87
Min Price:
316.87
Dimensions:
[10.0, 8.0, 1.0]
qty:
1
simpleSku:
NDkxNQ:::2HTF2
sku:
NDkxNQ::H9:2HTF2@x5
condition:
11
seller:
andersonprocess.com
amzMan:
dixon valve
HazMat:
False
DropShip:
False
Attributes
| Key ^ | Value |
|---|---|
| Body Size | 1/4" |
| Brand Name | DIXON? |
| Brand, Manufacturer | Dixon Valve & Coupling |
| Connection | Female NPT |
| Construction | Machined components are manufactured using solid bar stock; Stainless steel balls, retaining rings and springs maximize corrosion resistance and extend service life. Steel componentry is plated using ROHS Compliant Trivalent Chrome. Steel coupler sleeves are hardened to resist deformation and maximize service life. Couplers have polyurethane valve stem O-Ring, with a temperature range of -65? to +212?F; Ancillary coupler seals are Nitrile (Buna-N), with a temperature range of -40?F to +250?F; PTFE or TPC-ET Anti-Extrusion ring protects main coupling valve seal from dynamic impulse pressure damage. |
| Data | 7/8" Hex Size |
| Description: | 1/4 ISO16028 COUP, 1/4 F-NPTF STEEL |
| Dimensions | 1.11 in OD |
| End Style | FNPT |
| Features | High flow performance, compact profile; Easily rebuildable!; Bulkhead mountable sleeve for breakaway, multi-plate or Blindmate installations; DORS (dual opposing retention spheres) retention system prevents valve stem ejection during surge flow and pressure spike conditions. |
| Height (in) | 1.11 |
| Hex | 7/8" |
| Hex Size | 7/8 in |
| Interchange | Interchangeable to ISO16028; Parker FEM-Series, Snap-Tite 74-Series, Hansen FF, Aeroquip/Eaton FD89, Stucchi A/FIRG, Faster FFH/2FFN/2FFI, Safeway FF49-Series |
| Item | HTSeries Coupler ST 1/4",FemaleNPTF,1/4" |
| Length | 1.98 in, 1.98", 1.98" (50.3mm) |
| Length (in) | 1.98 |
| Manufacturer Part Number, MFG Part #:, MPN | 2HTF2 |
| Manufacturer, Supplier: | Dixon Valve & Coupling Co |
| Material | Steel |
| Maximum OD | 1.11" (29.3mm) |
| Nominal Size | 1/4 in - 18, 1/4-18 |
| Options | Contact Anderson Process for all available option adders; Standard seal options include: FKM, EPDM, FDA FKM, Mil-Nitrile, Fuel Nitrile and Silicone; Kalrez? seal options include: 4079, 6375 and 7075; Oxy-clean treatment is available |
| Package Quantity | 1/Each |
| Pressure Rating | 5000 psi |
| Product | Couplers |
| Product Type | Simple product |
| Series | HT-Series Flushface, HT Series |
| Specifications | Rated pressure for connected Steel Coupler and Steel Plug: 5,000 PSI (345 bar) Maximum Working and 20,000 PSI (1,379 bar) burst; Rated pressure for uncoupled Steel Coupler: 5,000 PSI (345 bar) Maximum Working and 20,000 PSI (1,379 bar) burst |
| Standard Approvals | RoHS Compliant |
| Thread | Female NPTF |
| Thread Size | 1/4"-18 |
| UPC, UPC: | 089109818693 |
| WARNING! | This product contains a chemical known to the State of California to cause birth defects or other reproductive harm. Do not use in connection with drinking water. Wash hands after handling. For more information go to www.P65Warnings.ca.gov |
| Weight | 0.310000 |
| Weight Lb | 0.3100 |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
 | andersonprocess.com | 2HTF2 | 44.63 | 44.63 | 1 | In Stock | 26 | Dixon Valve & Coupling | 0.31 | 44.63 @ Qty: 1+ |
 | Megadepot | 2HTF2 | 45.58 | 45.58 | 1 | In Stock | Dixon Valve | 0.31 | 45.58 @ Qty: 1+ | |
 | usmegastore.com | 2HTF2 | 45.58 | 45.58 | 1 | In Stock | Dixon Valve | 0.31 | 45.58 @ Qty: 1+ | |
 | heavydutydepot.com | 2HTF2 | 45.58 | 82.044 | 3 | In Stock | Dixon | 45.58 @ Qty: 3+ | ||
 | toolfetch.com | DIX-2HTF2 | 45.99 | 45.99 | 1 | In Stock | DIXON VALVE | 45.99 @ Qty: 1+ | ||
| kscdirect.com | DIX 2HTF2 | 48.89 | 48.89 | 1 | In Stock | Dixon Valve & Coupling Co | 48.89 @ Qty: 1+ | |||
| motionindustries.com | 04403569 | 55.2 | 55.2 | 1 | In Stock | Dixon Valve & Coupling Company, LLC | 55.2 @ Qty: 1+ | |||
 | Purvis | 2HTF2 | 57.16 | 57.16 | 1 | In Stock | Dixon Valve | 57.16 @ Qty: 1+ | ||
 | industrialzone.com | 2HTF2 | 64.24 | 141.328 | 4 | In Stock | Dixon | 0.31 | 64.24 @ Qty: 4+ | |
 | Zoro | G6565636 | 74.09 | 74.09 | 1 | In Stock | Dixon Valve & Coupling | 0.07 | 74.09 @ Qty: 1+ | |
 | hanessupply.com | 2HTF2-10639 | 89.03 | 89.03 | 1 | In Stock | Dixon Valve & Coupling | 89.03 @ Qty: 1+ | ||
 | Wilson | 2HTF2 | 159.9 | 159.9 | 1 | In Stock | Dixon | 159.9 @ Qty: 1+ |
