CAI - EATON CN15DN3BB

B007ICVZD4

Eaton Electrical - CN15DN3BB - 240VAC NEMA Magnetic Contactor; No. of Poles: 3, Reversing: No, 27 Full Load Amps

Eaton Electrical - CN15DN3BB - 240VAC NEMA Magnetic Contactor; No. of Poles: 3, Reversing: No, 27 Full Load Ampszoom

Attributes

Key Value
ActionNon-Reversing
Amps27
ApplicationCommercial / Institutio.
Auxiliary Contact Form1NO
Auxiliary Contacts1NO
BrandEaton
Catalog NumberCN15DN3BB
Certification ListingsCSA, UL
Coil TypeMagnetic
Coil Voltage240 VAC, 220-240VAC
Coil Volts240V AC
Depth5.6 in
Enclosure NEMA RatingNo Enclosure
Family / StyleFreedom
Family SeriesCutler Hammer, Div of E.
Frame / Series / Class .Series Freedom, Code A,.
Full Load Amps27 A
Gross Weight3 lbs
Height3.4 in
HP @ 1 Phase - 120V2 hp
HP @ 1 Phase - 240V3 hp
HP @ 230V (1ph)3
HP @ 230V (3ph)3
HP @ 3 Phase - 208V7 1/2 hp
HP @ 3 Phase - 240V7 1/2 hp
HP @ 3 Phase - 480V10 hp
HP @ 3 Phase - 575V10 hp
HP @ 460V (3ph)10
ItemMagnetic Contactor
Item NumberCN15DN3BB
ManufacturerCutler Hammer, Div of E.
Manufacturer Part NumberCN15DN3BB
Max HP 115V 1PH2 hp
Max HP 200/208V 3PH7.5 hp
Max HP 230/240V 1PH3 hp
Max HP 230/240V 3PH7.5 hp
Max HP 460/480V 3PH10 hp
Max HP 575/600V 3PH10 hp
NEMA Contactor Size1
NEMA Continuous Current.27 A
NEMA Frame Size1
Nema Size1
NEMA Size1
Net Weight3 lbs
Nominal Coil Voltage240 VAC
Number of Poles3
Overload RelaysC306, C396
Part NumberCN15DN3BB
Phase1
Poles3NO
Poles (Closed)3
Product Height5.05 in
Product Length/Depth4.44 in
Product SeriesFreedom
Product Width2.56 in
ReversingNo
Size1
StandardCSA Certified,UL Listed
TerminationBox Lug
UPC782113981420
Width4.8 in

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomsustainablesupply.comC2883493487.861In StockEaton3.0487.86 @ 1
thumbzoomkempstoncontrols.co.ukCN15DN3BB552.864781In StockEaton552.86478 @ 1
AmazonSCB007ICVZD4600.831In StockCAI - EATON600.83 @ 1
thumbzoommidwestapplianceparts.comCN15DN3BB-CU-P619.221In StockCutler Hammer619.22 @ 1
thumbzoomCarlton Bates Company78211398142648.231In StockEATON648.23 @ 1
thumbzoomZoroG3641942760.991In StockEaton3.0760.99 @ 1
AmazonTPB011OX7P1I768.431In Stock5CUTLER HAMMER768.43 @ 1
thumbzoomPlatt.com0670267794.931In StockEaton794.93 @ 1
thumbzoommotorsandcontrol.comCN15DN3BB818.131In StockEaton Cutler Hammer818.13 @ 1
thumbzoomturtle.comCUH CN15DN3BB826.821In StockEaton826.82 @ 1
thumbzoomGalcoCN15DN3BB-CHGP874.341In StockCutler Hammer, Div of Eaton Corp3.0874.34 @ 1
thumbzoomcrescentelectric.com51002904.581In StockEaton904.58 @ 1
simplybreakers.comCN15DN3BB934.991In StockEaton Cutler-Hammer934.99 @ 1
us.rs-online.com717901171042.7311Eaton - Cutler Hammer1042.73 @ 1
thumbzoomcappusa.com11575361083.911In StockEaton1083.91 @ 1
Newark46K15881138.6516EATON CUTLER HAMMER1138.65 @ 1
kirbyrisk.com5350861210.771In StockCutler Hammer1210.77 @ 1
