| (a) Outer Diameter, Top, (b) Outer Diameter, Bottom | 2.90 in (73.66 Mm) |
| (c) Inner Diameter, Top | 1.51 in (38.35 Mm) |
| (d) Inner Diameter, Bottom | 1.81 in (45.97 Mm) |
| (e) Length | 10.63 in (45.97 Mm) |
| (f) Thread, Filter Area, Plating, Seal Material | N/a |
| Beta Rating | B74=200 |
| Center Tube | Plated Steel |
| Collapse Pressure Rating | 150 Psid |
| Configuration | Double Open End |
| Direction of Flow | Outside->in |
| Handle | None |
| Maximum Temperature | 250 F |
| Micron Rating | 74.00 |
| Outer Jacket | Yes - Perforated |
| Recommended Changeout Differential Pressure | 0 Psid |
| Type of Adhesive | Epoxy |
| Type of End Cap | Plated Steel/alum |
| Type of Media | Wire Mesh |
