GRAINGER APPROVED 4VMU9

B0763JY8YN

Swing Check Valve, 316 SS, 3/8 In., Solder

Swing Check Valve, 316 SS, 3/8 In., Solderzoom

Attributes

Key Value
Application - ValvesGeneral Purpose
Body Material316 Stainless Steel
Body Material - Valves316 Stainless Steel
Cap to Inlet Center1 11/16 in
Connection TypeFNPT x FNPT, Socket Wel.
Cracking Pressure0.5 psi
Cracking Pressure - Che.0.500 psi
Flow5.1 gpm
Flow - Valves5.10 gpm, 5.1 gpm
Flow DesignSingle
Full Flow - ValvesYes
Hex Size1 1/16", 1 1/16 in
ItemSwing Check Valve
Item - Check ValvesCheck Valve
Length2-9/16", 2 9/16 in
Length (Straight Wirewa.2 9/16 in
Max. Steam Pressure - V.200 psi WSP
Max. Temp.353 Degrees F
Max. Temp. - Valves350 Degrees F, 350 Deg.
Max. Water Pressure200 psi
Max. Water Pressure - V.200 psi
Mechanism and Body Desi.Inline Swing
Min. Temp. - Valves-4 Degrees F, -4 Degre.
Mounting OrientationHorizontal
Mounting PositionHorizontal
Overall Height2-9/16", 2 9/16 in
Pipe or Tube Size3/8 in
Pipe or Tube Size - Che.3/8"
Pipe Size3/8"
Seal MaterialPTFE
Size3/8"
Sub-CategoryStainless Steel
Width1 53/64 in, 1-53/64"

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomZoroG227330239.9911Zoro Select0.7239.99 @ 1
grainger.caGGM4VMU960.191091581In StockGRAINGER APPROVED0.7260.19109158 @ 1
