CAI - HAMMOND VALVE 968 1/2

B000R8EXDU

Swing Check Valve, Brass, 1/2 In., Solder

Swing Check Valve, Brass, 1/2 In., Solderzoom

Attributes

Key Value
Application - ValvesGeneral Purpose
Body MaterialBrass
Body Material - ValvesBrass
Cap to Inlet Center1 17/32 in
Connection TypeSolder
Connection Type - Check.FNPT x FNPT
Country of Origin (subj.China
Cracking Pressure0.75 to 1 psi
Cracking Pressure - Che.0.750 to 1.000 psi
Flow - Valves10.0 gpm
Flow DesignSingle
Full Flow - ValvesYes
ItemSwing Check Valve
Item - Check ValvesCheck Valve
Length2 17/32 in
Length (Straight Wirewa.2 17/32 in
Material of ConstructionBrass
Max. Pressure200 psi WOG
Max. Steam Pressure - V.Not Rated
Max. Water Pressure200 psi Non Shock CWP
Max. Water Pressure - V.200 psi @ 150 Degrees F
Mechanism and Body Desi.Inline Swing
Min. Temp. - Valves-20 Degrees F
Mounting OrientationHorizontal, Vertical
Mounting Orientation - .Horizontal, Vertical
Mounting PositionVertical or Horizontal
Pipe or Tube Size1/2 in
Pipe or Tube Size - Che.1/2 in
Pipe Size1/2"
Seal MaterialBrass
Seal Material - Check V.Brass
Seat MaterialBrass
Seat Material - Check V.Brass
Size1/2"
StandardsASTM B584
Sub-CategoryBrass
