HARTING ELECTRONICS 09672154704 15 Position D-Sub Receptacle Female Sockets Connector - 5 item(s)
- Brand: HARTING ELECTRONICS
- PartNumber: 09672154704
- Model: 09672154704
- PackageQuantity: 1
- Manufacturer: HARTING ELECTRONICS
- Label: HARTING ELECTRONICS
Attributes
| Key | Value |
|---|
| Application | Standard |
| Backset Spacing | - |
| Cable Clamping Method | Solder Cup |
| Category | Connectors, Interconnec. |
| Color | - |
| Connection Type | Solder, PCB To Cable ; . |
| Connector Gender | Female |
| Connector Style | D-Sub |
| Connector Type | Receptacle, Female Sock. |
| Contact Finish | - |
| Contact Finish Thickness | - |
| Contact Form | Stamped |
| Contact Material | Copper Alloy |
| Contact Plating | Noble Metal Over Ni |
| Contact Resistance | 10 mOhms |
| Contact Type | Signal |
| Current Rating | 6.5 A |
| Current Rating (Amps) | 6.5A |
| D-Sub Shell Size | D-Sub 2 |
| Description | CONN D-SUB RCPT 15POS S. |
| Detailed Description | 15 Position D-Sub Recep. |
| Dielectric Material | Polybutylene Terephthal. |
| Digi-Key Part Number | 1195-2757-ND |
| Features | - |
| Flange Feature | Housing/Shell (Unthread. |
| Gender | Female |
| Housing Material | Plated Steel |
| Ingress Protection | - |
| Insert Color | Black |
| Insert Material | Thermoplastic Resin Gla. |
| Insulation Resistance | 10000000000 Ohms |
| Item | Fixing Flange D-Sub Con. |
| Locking Type | Fixing Flange |
| Manufacturer | HARTING |
| Manufacturer Product Nu. | 09672154704 |
| Manufacturer Standard L. | 13 Weeks |
| Material Flammability R. | UL94 V-0 |
| Maximum Contact Resista. | 10 megaohm |
| Maximum Operating Tempe. | 85 Degrees C |
| Mfr | HARTING |
| Minimum Insulation Resi. | 1.00 x 10^10 ohm |
| Minimum Mating Cycles | 50 |
| Minimum Operating Tempe. | -40 Degrees C |
| Mounting Type | Free Hanging (In-Line) |
| Number of Contacts | 15 |
| Number of Poles | 15 |
| Number of Positions | 15 |
| Number of Rows | 2 |
| Operating Temperature | -40?C ~ 85?C |
| Operating Temperature R. | -40 Degrees C to 85 D. |
| Package | Bulk |
| Product Status | Active |
| Series | D-Sub, -, D-Sub Series |
| Service Connector Type | Standard Density D-Sub . |
| Shell Material, Finish | Steel |
| Shell Size, Connector L. | 2 (DA, A) |
| Size | D-Sub 2 |
| Standards | DIN 41652, UL 1977 ECBT. |
| Termination | Solder Cups, Solder Cup |
| Type | Female |
| Voltage Rating | - |
| Weight | 6.600 g |
| Wire Gauge | 20 AWG |
| Wire Size | 20 AWG |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
| Hotenda | H809047 | 3.1 | 1 | 5 | | HARTING | | 3.1 @ 5 |
| us.rs-online.com | 70574780 | 3.5 | 1 | 70 | | HARTING | 0.01452 | 3.5 @ 5 |
| RS Delivers | 139-3689 | 3.5088 | 1 | 5 | | HARTING | | 3.5088 @ 5 |
| Future Electronics | 6089949 | 3.54 | 1 | 33 | | HARTING | | 3.54 @ 5 |
 | Newark | 44J6303 | 3.97 | 1 | 50 | | HARTING | | 3.97 @ 5 |
 | Digi-Key | 3181341 | 4.548 | 1 | 5 | | HARTING | | 4.548 @ 5 |
 | Zoro | G505285923 | 8.85 | 3 | 5 | | Harting | 1.45 | 8.85 @ 5 |
