HIROSE(HRS) DF3A-5P-2DS

B08X1HDWDK

Hirose(Hrs) Wire-to-Board Connector, Right Angle, Df3 Series, Through Hole, Header, 5, 2 Mm Rohs Compliant: Yes - DF3A-5P-2DS

Hirose(Hrs) Wire-to-Board Connector, Right Angle, Df3 Series, Through Hole, Header, 5, 2 Mm Rohs Compliant: Yes - DF3A-5P-2DSzoom

Attributes

Key Value
Applications-
Base Product NumberDF3A
CategoryConnectors, Interconnec.
Connector TypeHeader
Contact Finish - MatingTin
Contact Finish - PostTin
Contact Finish Thicknes.-
Contact Finish Thicknes.-
Contact Length - Mating0.122" (3.10mm)
Contact Length - Post0.114" (2.90mm)
Contact MaterialBrass
Contact ShapeSquare
Contact TypeMale Pin
Current Rating (Amps)3A
DescriptionCONN HEADER R/A 5POS 2MM
Detailed DescriptionConnector Header Throug.
Digi-Key Part NumberH3896-ND
Fastening TypePush-Pull
Features-
Ingress Protection-
Insulation ColorBlack
Insulation Height0.197" (5.00mm)
Insulation MaterialPolyamide (PA), Nylon
ManufacturerHirose Electric Co Ltd
Manufacturer Product Nu.DF3A-5P-2DS
Mated Stacking Heights-
Material Flammability R.UL94 V-0
MfrHirose Electric Co Ltd
Mounting TypeThrough Hole, Right Ang.
Number of Positions5
Number of Positions Loa.All
Number of Rows1
Operating Temperature-55?C ~ 105?C
Overall Contact Length-
PackageBulk
Pitch - Mating0.079" (2.00mm)
Product StatusActive
Row Spacing - Mating-
SeriesDF3
ShroudingShrouded - 4 Wall
StyleBoard to Board or Cable
TerminationPress-Fit, Solder
Voltage Rating-

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomRadwellDF3A-5P-2DS0.21010HIROSE ELECTRIC0.2 @ 10
Future Electronics30012680.20410010Hirose Electric0.204 @ 100
thumbzoomNewark24R60340.24210100HIROSE(HRS)0.242 @ 10
thumbzoomDigi-Key5604620.261134159Hirose Electric Co Ltd0.261 @ 10
thumbzoomComponent Electronics299-117390.27110Hirose Electric0.27 @ 10
RS Delivers700-84330.3276150Hirose0.3276 @ 10
