Attributes
| Key | Value |
|---|---|
| Amperage | 60A |
| Amperage Rating | 60A |
| Amps | 60 |
| Amps - Plugs and Receptacles | 60 |
| Application | Metallic with Nylon Shroud |
| Approvals | CSA, UL |
| Aux/Pilot Contacts | None |
| AWG Range | #6 AWG to #4 AWG |
| Body Material | Valox 357 Housing and Aluminum Shroud |
| Body Material - Pin and Sleeve | Valox 357 Housing and Aluminum Shroud |
| Built-In Strain Relief | Yes |
| Cap Type | No Cap or Cover |
| Case Material | Non-Metallic |
| Color | Gray |
| Color - Plugs and Receptacles | Gray |
| Color Family | Gray |
| Compatible with Series | Insulgrip |
| Connection Description | Water Resistant |
| Connection Orientation | Straight |
| Country of Origin | US - United States |
| Country of Origin (subject to change) | United States |
| Current Rating | 60 A |
| Display Type | Standard Sized |
| ECCN | EAR99 |
| Family Series | Hubbell Plugs & Receptacles, Insulgrip Series |
| Features | Ground Through Metallic Shroud, Watertight and Abuse Resistant |
| For Maximum Cable Diameter | 1.45 in |
| For Minimum Cable Diameter | 0.5 in |
| Gross Weight | 2.55 lbs |
| Grounding | Grounded |
| Grounding Style | 1 |
| Housing Color | Black, Gray |
| Housing Material | Non-Metallic |
| Housing Material Grade | Valox 357 |
| HP | - |
| IP Rating | Not Rated |
| Item | Type 4X Pin and Sleeve Plug |
| Item - Plugs and Receptacles | Watertight Pin and Sleeve Plug |
| Item Number | HBL460PS1W |
| Lockout-Tagout | No |
| Manufacturer | Hubbell |
| Manufacturer Part Number | HBL460PS1W |
| Material | Composite |
| Maximum Operating Temperature | 75 Degrees C |
| Maximum Wire Size | 4 AWG |
| Minimum Operating Temperature | -40 Degrees C |
| Minimum Wire Size | 6 AWG |
| NEMA Enclosure Rating | 4X |
| Net Weight | 0 lbs |
| No. of Poles | 3 |
| No. of Wires | 4 |
| Number of Poles | 3 |
| Number of Wires | 4 |
| Outside Diameter | 3.4 in |
| Overall Length | 9.4 in |
| Phase | 3 |
| Phase - Electrical | 3 |
| Pin & Sleeve Standards | UL 1682 |
| Power Indicating Light | No |
| Product Series | Insulgrip |
| Rated Voltage | 600V AC/250V DC |
| Resistance Properties | Impact Resistant, Moisture Resistant, Watertight |
| Reverse Service | No |
| Shrouded | Yes |
| Standard | CSA Certified to CSA Spec. C22.2 No. 159;UL Listed and CSA Certified Type 4X;UL Standard 1682,UL 50, and UL 1010 |
| Standards | CSA Certified C22.2 No. 182.1, No. 94 and No. 159, UL Listed 1682, UL50 and UL1010 |
| Style | Standard Service,Style 1 Grounding |
| Switch Rated | No |
| Temperature Range (F) | -40-167 ?F |
| Terminal Type | Screw |
| Type | Watertight Plug |
| UL 94 Flammability Rating | V-0 |
| UNSPSC | 39121402 |
| Voltage | 600VAC/250VDC, 600 V, 250V DC/600V AC |
| Voltage - Plugs and Receptacles | 600V AC/250V DC |
| Voltage Color Code | Black, Gray |
| Voltage Rating | 250V DC, 600V AC |
| Wire Connection Type | Screw Terminals |
| Wire Size | 4 AWG, 5 AWG, 6 AWG |
| Wire Size Range | 6-4 AWG |
