Hubbell Wiring Device-Kellems BR15GRYWR

B0078S0MKU

Receptacle, Duplex, 15A, 5-15R, 125V, Gray

Receptacle, Duplex, 15A, 5-15R, 125V, Grayzoom

Attributes

Key Value
Accessory Group-
Additional Electrical P.Standard Protection
Additional Electrical P.Standard Protection
AFCINo
Amperage15 A
Amperage Rating15A
Amps15
Amps - Plugs and Recep.15
Amps - Plugs and Recept.15 A
ApplicationCommercial Specificatio.
Application EnvironmentCommercial
ApprovalsCSA, UL
AWG Range#14 AWG to #10 AWG
Boot Code-
ColorGray
Color - Plugs and Recep.Gray
Color FamilyGray
CommentsCommercial Specificatio.
Connection OrientationStraight
ConnectivityBack and Side Wired
Contact MaterialBrass
Corrosion ResistantNo
Country of OriginCN - China
Country of Origin (subj.China
Cover TypeNo Cover
Current / amperage rati.15 A
Current Rating15 A
Current rating15 A
DescriptionGrounding, Smooth
Dielectric strengthWithstands 2,000V minim.
Dimensions1.32 in x 0.83 in x 3.2.
Display TypeStandard Sized Product
ECCNEAR99
Environmental conditionsWeather Resistant
Face Plate Height2.73 in
Face Plate Width1.32 in
Family SeriesHubbell Plugs & Recepta.
Flange TypeNon-Flanged
GFCINo
GradeFederal Specification
Gross Weight0.15 lbs
GroundGrounding
GroundingGrounded
Height3.28 in., 3.28 in
Horsepower Rating1/2 hp
Housing ColorGray
Housing ColourGray
Housing MaterialNylon
HP0.5, 1/2 hp
IlluminatedNo
IncludesGrounding Staple, Mount.
Includes Mounting Hardw.Yes
Isolated GroundNo
ItemReceptacle
Item - Plugs and Recept.Receptacle
Item NumberBR15GRYWR
Key Resistance Properti.Weather Resistant
Lampholder Watts1875W
Length1.32 in, 1.32 in.
ManufacturerHubbell
Manufacturer Part NumberBR15GRYWR
MarketCommercial, Industrial
MaterialNylon
Material - mounting har.Screw Mounting
Max HP0.5
Maximum Operating Tempe.75 Degrees C, 75 Degre.
Maximum Wire Size10 AWG
Minimum Operating Tempe.-40 Degrees C, -40 Deg.
Minimum Wire Size14 AWG
Mount Hole Center-to-Ce.3.28 in
Mount TypeFlush
Mounting TypeFlush
Mounting Type - Plugs a.Flush
Multimedia OutletNo
NEMA Configuration5-15, 5-15R
NEMA Enclosure Rating1
Nema Rating5-15R
NEMA Receptacle Configu.5-15R
NEMA Receptacle Configu.5-15R
Net Weight0 lbs
No. of Poles2
No. of Wires3
Number of Gangs1
Number of poles2-Pole
Number of Poles2
Number of Poles & Wires2 Pole / 3 Wire
Number of Wires3
Number of wires3-Wire
Operating temperatureMaximum continuous 75C .
Outlet TypeDuplex
Outlet Type - Plugs and.Standard Duplex
Overall Depth3.28 in
Phase1, Single, Single phase
PolarizedYes
Power IndicatorNo
Primary Resistance Prop.Weather Resistant - Wea.
Product TypeReceptacle
Rated Voltage125V
Receptacle TypeDuplex
Resistance PropertiesWeather Resistant
ShroudedNo
StandardCertified to CSA C22.2,.
StandardsCertified to CSA C22.2,.
StyleSmooth Face
Sub-CategoryDuplex Receptacles
Surge ProtectionNo
Surge SuppressionNo
Tamper ResistantNo
TypeDuplex, Weather Resista.
UL 94 Flammability Rati.V-2
UNSPSC39121406
USBNo
Voltage125VAC, 125 V, 125 VAC
Voltage - Plugs and Rec.125V AC
Voltage Rating125V AC
Voltage rating descript.125 V
Wattage1875 W
Weather ResistantYes
Weather Resistant - Plu.Yes
Width0.83 in.
Width (in)0.83
Wire Connection TypeScrew Terminals
Wire Connection TypesScrew Terminals
Wire size#14 AWG to #10 AWG
Wiring MethodBack, Side
Wiring Method - Plugs a.Back and Side

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomZoroG20806015.561In StockHubbell1.55.56 @ 1
Onlinecomponents.comBR15GRYWR5.611In StockHubbell5.61 @ 1
thumbzoomMRO Supply10152586.296In StockHubbell Wiring6.29 @ 6
thumbzoomGalcoBR15GRYWR-HBBL6.471In StockHubbell0.156.47 @ 1
Graybar251721346.98881In StockHubbell Wiring Device - Kellems6.9888 @ 1
thumbzoomsustainablesupply.comC118026411.191In StockHubbell0.1611.19 @ 1
Newark84M895111.581In StockHUBBELL WIRING DEVICES11.58 @ 1
grainger.caHBLBR15GRYWR17.208860261In StockHUBBELL WIRING DEVICE-KELLEMS0.1617.20886026 @ 1
thumbzoomRaptor SuppliesAC2AKG17.87761In StockHUBBELL WIRING DEVICE-KELLEMS17.8776 @ 1
