Hubbell Wiring Device-Kellems WS2000I

B00HY1MAOW

Occupancy Sensor, PIR, 1200 sq ft, Ivory WS2000I

Occupancy Sensor, PIR, 1200 sq ft, Ivory WS2000Izoom

Attributes

Key Value
AC Voltage120 VAC, 277 VAC
Amperage8.3 A
ApplicationCompatible with most LE.
ApprovalscULus
ASINB00HY1MAOW
Base Unit of MeasureEA
Batteries Required?No
BOX SIZE3.600x3.000x11.800 (in)
BrandHubbell Wiring Device-K.
Carton1
Carton - Gross Weight p.3.900 lb.
Carton - Number of Sub .10
Carton - Pack Descripti.Carton
Carton - SCC-14 Next Lo.783585256306
Carton - Total Units10 EA
Case Weight0.000
Category DescriptionResidential Dimmers, Mo.
CertificationRoHS
Class CodeA48
ClassificationResidential Dimmers, Mo.
ColorIvory
Color - Motion Sensing .White
Color FamilyIvory
CommentsPassive Infrared Techno.
Communication Method - .Hard Wired
connectorTerminal Screws
Country of OriginTW, TAIWAN, TW - Taiwan
Coverage1200 sq. ft., 1200 ft?
Coverage (Degrees / Squ.178/1200
Coverage Angle - Motion.180 Degrees
Coverage Area (sq ft)1,200
Coverage at Suggested M.1,200 sq ft
Current Stock397
DescriptionOCC/VAC SENSOR,PIR,120/.
Description - InvoiceOCC/VAC SENSOR,PIR,120/.
Description/Special Fea.3-Way Capable, Selectab.
Dimenions4.15 in. x 1.82 in. x 1.
DimensionsFace 2.59"H x 1.30"W, 0.
Each - Pack DescriptionEach
Each - Width2.300 in
ECCNEAR99
environmental conditionsIndoor Dry unless prote.
EU RoHS IndicatorNo
extra long descriptionHWDK WS2000I OCC/VAC SE.
Family SeriesHubbell Switches
FeaturesStandard Passive Infrar.
Freight Class Code06168002
Green Environmental Att.Product Contributes To .
Gross Weight0.25 lbs
GTIN00783585256306
Harmonization Code8536507000
Height1.62 in, 2.300
Humidity20% to 90% non-condensi.
Image Actual Or Represe.A
IncludesNylon Wall Plate, Photo.
Indicator(s) TypePIR= Red LED
Indicator(s) typePIR= Red LED
Industry Standard(s)cULus Listed To UL773A
Installation Location -.Wall Switch Box
Installation TypeWall Mount
International ShippingNo
Item - Motion Sensing a.Motion Sensor
Item model numberWS2000I
Item NumberWS2000I
Item Package Quantity1
Item TypePassive Infrared Wall S.
Item typePassive Infrared Wall S.
Lead TimeExpected to ship in 1-2.
Length4.15 in, 4.800
Lighting Sensor TypePassive Infrared
Lighting TechnologyFluorescent, Incandesce.
loadLighting Circuit
Long DescriptionLighting Controls, Occu.
Lowest Level UOMEach
ManufacturerHubbell
Manufacturer Part NumberWS2000I
Manufacturers Part Numb.WS2000I
MaterialABS Thermoplastic, ABS,.
Max. Capacity @ 277VAC1800W (Fluorescent, Inc.
MountingMounting Screws
Mounting Height3.5-4.5 ft, 42 to 54 in.
MpnWS2000I
MSDS FlagNo
Net Weight0 lbs
Operating temperature32F to 122F (0C to 50C).
Operating Temperature32?F to 122?F (0?C to 5.
Operating Voltage - Mot.120 V AC, 277 V AC
Package10
Package Quantity1
pallet quantity1350
Part NumberWS2000I
PerformanceControls - Ambient Ligh.
PhotocellYes
Product TypeOcc/Vac Sensor, Pir, 12.
Rated Voltage120/277V ac
Replaced Catalog NumberWS1277I;WS1277MI;WS277I.
sensing range1000 Square Feet
Sensing TechnologyPassive Infrared
Sensor TypePassive Infrared
seriesPassive Infrared
SeriesPassive Infrared
Size4.15 in x 1.82 in x 1.6.
Size MeasureIN
SKUZO-G5238134
Special FeaturesStandard Product
StandardcULus Listed To UL773A
standardcULus Listed To UL773A
Standards - RoHS Compli.CM
Storage Temperature Ran.-40?F to 150?F (-40?C t.
Storage temperature ran.-40F to 150F (-40C to 6.
sub brandH-MOSS
Sub Class CodeA48A450
SubCategoryLighting
Suggested Mounting Heig.3 ft 6 in to 4 ft 6 in
supply voltage120/277 AC
Switch ConfigurationSingle Pole, Three Way
Switch Type3-Way
Time DelayAdjustable - 20s-30m
Time Delay - Motion Sen.20 sec to 30 min
Time Delay Adjustment M.Manual
Time Delay TypeAdaptive/Manual
Timer Range5 to 30 Minutes, 20 sec.
TypeManual/Auto
UNSPSCN/A, 39122236
UPC783585256306
UPC Code783585256306
Viewing Angle180 Degrees
Voltage120/277 VAC
Voltage Rating120/277, 120/277 VAC
Voltage Rating Descript.120/277V ac
Voltage rating descript.120/277V ac
Watts @ 120V1000
Watts @ 277V1800
Weight0.350
Weight MeasureLB
Weight per each0.25
Width2.300 in, 3.100
Width (in)1.82

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomsustainablesupply.comC117388163.231In StockHubbell0.3563.23 @ 1
thumbzoomturtle.comHUB WS2000I63.231In StockHubbell63.23 @ 1
thumbzoomGalcoWS2000I-HBBL63.811In StockHubbell0.2563.81 @ 1
thumbzoomAmazonB00HY1MAOW64.521In StockHUBBELL WIRING DEVICES0.3564.52 @ 1
thumbzoomHD Supply37460564.791In StockHubbell0.3564.79 @ 1
AmazonTPB00HY1MAOW64.991In Stock2HUBBELL WIRING DEVICES64.99 @ 1
Onlinecomponents.comWS2000I68.8112HUBBELL68.81 @ 1
thumbzoomZoroG523813472.691617Hubbell Wiring Device-Kellems0.3572.69 @ 1
Graybar2557229077.548813Hubbell Wiring Device - Kellems77.5488 @ 1
cbtcompany.comWS2000I78.721In StockHubbell Wiring Device-Kellems78.72 @ 1
thumbzoommayerelectric.comHUBWS2000I81.7618HUBBELL WIRING DEVICES3.981.76 @ 1
thumbzoomsimsupply.comZO-G523813486.141397Hubbell Wiring Device-Kellems86.14 @ 1
thumbzoomgordonelectricsupply.comWS2000I97.371In StockHUBBELL97.37 @ 1
thumbzoomMRO Supply5022160100.791In StockHubbell Wiring100.79 @ 1
thumbzoomRaptor SuppliesAF7YWD111.0198961In StockHUBBELL WIRING DEVICE-KELLEMS111.019896 @ 1
kirbyrisk.com2571922111.72111Hubbell111.72 @ 1
us.rs-online.com71528713113.411In StockHubbell Wiring Device-Kellems113.41 @ 1
thumbzoomNational Supply Network98653793121.931In StockHubbell Wiring Device-Kellems121.93 @ 1
thumbzoomElliott ElectricWS2000I140.961In StockWiring Device-Kellems0.25140.96 @ 1
thumbzoomNewark17X0399174.261In StockHUBBELL WIRING DEVICES174.26 @ 1
