IGBT Transistors GBT666x

B0151BBOOS

INTERNATIONAL RECTIFIER IRG4BC30WPBF SINGLE IGBT 600V 23A

INTERNATIONAL RECTIFIER IRG4BC30WPBF SINGLE IGBT 600V 23Azoom

Attributes

Key Value
Alternate Part No.942-IRG4BC30WPBF
BrandInternational Rectifier
CategoryDiscrete Semiconductor .
Collector- Emitter Volt.600 V
Collector-Emitter Satur.2.7 V
ConfigurationSingle
Continuous Collector Cu.23 A
Current - Collector (Ic.23 A
Current - Collector Pul.92 A
Gate Charge51 nC
IGBT Type-
Input TypeStandard
ManufacturerInternational Rectifier
Manufacturer Part No.IRG4BC30WPBF
Maximum Gate Emitter Vo.+/- 20 V
MfrInternational Rectifier
Minimum Operating Tempe.- 55 C
Mounting StyleThrough Hole
Mounting TypeThrough Hole
Operating Temperature-55?C ~ 150?C (TJ)
PackageBulk
Package / CaseTO-220-3
Package/CaseTO-220-3
PackagingTube
Part StatusActive
Power - Max100 W
Power Dissipation100 W
Product CategoryIGBT Transistors
Series-
Supplier Device PackageTO-220AB
Switching Energy130?J (on), 130?J (off)
Td (on/off) @ 25?C25ns/99ns
Test Condition480V, 12A, 23Ohm, 15V
Vce(on) (Max) @ Vge, Ic2.7V @ 15V, 12A
Voltage - Collector Emi.600 V

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
Digi-Key125912001.331063829792358201International Rectifier1.33106382979 @ 235
thumbzoomswatee.comIRG4BC30WPBF5.8311288International Rectifier5.83 @ 1
