Kodiak Controls KC301L2560/DSF14-M

B01L1C231O

Kodiak Controls KC301L2560/DSF14-M Pressure Gauge on Flush Seal, 60 psi

Kodiak Controls KC301L2560/DSF14-M Pressure Gauge on Flush Seal, 60 psizoom

Attributes

Key Value
Accuracy ScaleFull Scale
Adjustable PointerNo
Ambient Operating Tempe.20 Degrees to 160 Degr.
Basic Gauge Case Materi.Stainless Steel
Basic Gauge Lens Materi.Plastic
Basic Gauge Sensor Mate.Stainless Steel
Basic Gauge Socket Mate.Stainless Steel
Basic Gauge Wetted PartsStainless Steel
Bezel Mounting TypeCrimped
Blowout Safety BackNo
Calibration Certificate.No
Case ColorSilver
Case ConstructionCorrosion Resistant
Case Depth1.28 in
Case Diameter2.8 in
Case MaterialStainless Steel
Cleaned for Oxygen Serv.No
Clog ResistantYes
Compatible Process MediaPaints, Pastes, Syrups,.
Connection LocationBottom
Connection Size1 in MNPT
Country of Origin (subj.China
Dial ColorWhite
Diaphragm Seal Process .Threaded
Diaphragm Seal TypeWelded
Dry Dampening FeatureNone
Field FillableYes
For Use WithThick or Solidifying Me.
Freeze Resistant Moveme.No
Gauge Accuracy+/-1.60%
Gauge ApplicationGeneral Purpose with Se.
Gauge Case ColorStainless Steel
Gauge Case LiquidGlycerin
Gauge Case Material304 Stainless Steel
Gauge Connection Locati.Bottom
Gauge Connection Size1 in
Gauge Connection TypeMNPT
Gauge Filled WithGlycerin
Gauge Lens MaterialPlastic
Gauge Nominal Dial Size2 1/2 in
Gauge Panel MountableNo
Gauge Primary Range Num.10
Gauge Primary Range Sma.1
Gauge Primary Range Uni.psi
Gauge Primary Range Val.0 to 60
Gauge Sensor Material316 Stainless Steel
Gauge Socket Material316 Stainless Steel
Gauge Special OptionsHeavy Duty
Graduations10 psi
Hazardous Location Rati.Not Rated
IncludesMini Flush Diaphragm Se.
Includes Calibration Ce.NIST with Data
Includes Mounting Hardw.No
Includes Vent PlugNo
IP/NEMA RatingNEMA 4X
ItemPressure Gauge with Dia.
Lens MaterialPolycarbonate
Liquid FilledYes
Liquid-Filled CaseYes
Manufacturer Warranty L.1yr
Manufacturers Warranty .1 yr
Nominal Dial Size2 1/2 in
Operating Temp. Range-30 Degrees to 200 Deg.
Panel-MountableNo
Pointer ColorBlack
Pointer MaterialAluminum
Pressure and Vacuum Gau.Pressure Gauge
Pressure Gauge TypeIndustrial Pressure Gau.
Pressure Range TypePressure
Primary Pressure Range0 to 60
Primary Scale Minor Gra.1
Primary Scale Numeric I.10
Primary Scale Unitspsi
Process Connection Gend.Male
Process Connection Loca.Bottom
Process Connection Size1/4 in
Process Connection TypeNPT
Range0 to 60 PSI
Removable BezelNo
Scale TypeDual
Seal Compatible Process.Air or Liquid Compatibl.
Seal Connection Size1 in
Seal Diaphragm Material316 Stainless Steel
Seal External Material316 Stainless Steel
Seal Fill LiquidMineral Oil
Seal Lower Housing Mate.316 Stainless Steel
Seal Maximum Working Pr.2,500 psi
Seal Process Temperatur.-40 Degrees to 328 Deg.
Secondary Pressure Range0 to 4
Secondary Pressure Scal.Blue
Secondary Scale Unitsbar
Sensor Material316 Stainless Steel
Smallest Graduation1 psi
Socket Material316 Stainless Steel
Vibration ResistanceLiquid-Filled

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomZoroG1835569171.791In Stock26Kodiak1.3171.79 @ 1
Grainger45MU06262.51In Stock10KODIAK262.5 @ 1
