Leeson 110493

B00BC8KIGU

General Purpose Farm Duty Motor, 3/4 HP

General Purpose Farm Duty Motor, 3/4 HPzoom

Attributes

Key Value
Alternate Mfr Part Numb.M6C17FC13J
Amperage Rating10.8/5.4 A
Amps10.8/5.4
Application TypeFarm Duty Motors, Fan a.
ApprovalsCSA, UL
Bearing TypeBall, 11.31
BearingsBall
BrandLeeson
CategoryElectric Motor
Class/GroupM6C17FC13
ColorRed
CompositionSteel
Current Rating10.8 ; 5.4 A
Current Stock9
Description:3/4HP..1725RPM.56.TEFC..
Dimensions11.48 in L
Drive End Bearing Size6203
Drive End Bearing TypeBall
Duty CycleContinuous
Efficiency70.0%, 70 %, 70
EnclosureTEFC, Totally Enclosed .
Enclosure MaterialRolled Steel
Enclosure TypeTEFC (Totally Enclosed .
Family SeriesLeeson Motors, Agricult.
Frame56C
Frame MaterialRolled Steel
Frame RemarksFarm Duty, FOOTLESS
Frequency60, 60 Hz
Frequency Rating60 Hz
Gross Weight0 lbs
Horsepower0.75 HP, 3/4 hp
Horsepower Rating0.75 HP
HP3/4, 0.75
Hz60
Insulation ClassB, Class B
Insulation TypeClass B
International ShippingNo
ItemFarm Duty Motor
Item ConditionFACTORY NEW
Item Number110493.00
KW0.56
Lead TimeExpected to ship in 1-2.
Length Less Shaft9 5/8 in
ManufacturerLEESON ELECTRIC CORPORA.
Manufacturer Part Number110493.00
Manufacturers Warranty .1 yr
MaterialRolled Steel
Maximum Ambient Tempera.40? C
MFG Part #:110493.00
Model NumberM6C17FC13
Motor ApplicationFarm Duty
Motor DesignCapacitor-Start
Motor Enclosure DesignTotally Enclosed Fan-Co.
Motor Frame MaterialSteel
Motor Mounting PositionHorizontal
Motor Mounting TypeFace
Motor Service Factor1.15
Motor Shaft DesignKeyed
Motor Shaft RotationCW/CCW
Motor Shell Length6.00"
Motor Sub ApplicationHigh Torque
Motor Thermal ProtectionManual
MountingRound
mountingC-face (NO base)
Mounting TypeC-Face Less Base, Round.
Mpn110493.00
Nameplate RPM1,725
NEMA Frame56C
Net Weight29 lbs
Nominal Voltage208 VAC, 240 VAC
Number of Poles4
Number of Speeds1
Opp. Drive End Bearing .6203
Opp. Drive End Bearing .Ball
Overall Length11.48", 11 1/2 in, 11.3.
Phase1, Single, 1 Phase, 1 ph
Product SeriesAgricultural Duty
Product TypeCapacitor Start
RotationSelective CCW, Reversib.
RPM1725 RPM, 1,800 RPM, 17.
RPM Range1,701-1,800
Service Factor1.15
Shaft Dia.5/8 in
Shaft Diameter0.625", 0.625, UL;CSA
Shaft Length1.88", 1.88, 1 7/8 in
Shaft Size0.63 in Dia x 1.88 in L
Ship Weight28 lbs.
SKUZO-G4608357
Special FeaturesService Factor - 1.15, .
StandardsUL Recognized, CSA (LR2.
SubCategoryMotors/Ac Motors
Supplier:LEESON ELECTRIC CORPORA.
Supply Voltage115/208-230 VAC
Thermal ProtectionManual
TypeCapacitor Start Inducti.
UPC691720009000
UPC Code691720009000
UPC:691720009000
Voltage115/208-230V AC, 115/20.
Volts115/208/230, 115/208-230

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomelectricmotorwholesale.com110493264.01In Stockleeson264.0 @ 1
AmazonTPB01M2Y2G57320.551In Stock5Leeson / Regal Beloit320.55 @ 1
thumbzoomMRO Supply2525515364.721In StockLeeson364.72 @ 1
thumbzoomZoroG4608357364.99118Leeson27.8364.99 @ 1
thumbzoomemotorpro.com110493.00404.761In StockLeeson28.0404.76 @ 1
thumbzoomsimsupply.comZO-G4608357432.0219Leeson432.02 @ 1
thumbzoomGalco110493.00-LEES437.851In StockLeeson29.0437.85 @ 1
us.rs-online.com72239215444.711In StockLeeson444.71 @ 1
kscdirect.comLEE 110493.00456.521In StockLEESON ELECTRIC CORPORATION456.52 @ 1
thumbzoomDealers Electric110493.00518.721In StockLeeson28.0518.72 @ 1
thumbzoomWalker Industrial110493-00521.131In Stock10Leeson521.13 @ 1
thumbzoomGlobal IndustrialWBB2176011075.01In StockLeeson1075.0 @ 1
thumbzoomRaptor SuppliesAJ2QDJ1083.9859291In StockLEESON1083.985929 @ 1
thumbzoompumpproducts.com110493.001143.921In StockLeeson1143.92 @ 1
