Leeson 122168.00

B078XPMHLP

Leeson 1HP 1800RPM.145TC.TENV.230/460V.3PH.60HZ.CONT.40C.1.0 (122168.00)

Leeson 1HP 1800RPM.145TC.TENV.230/460V.3PH.60HZ.CONT.40C.1.0 (122168.00)zoom

Attributes

Key Value
Amperage Rating3.2/1.6 A
Amps3.2/1.6
Bearing TypeBall
BearingsBall
CategoryElectric Motor
CompositionSteel
Country of Origin (subj.United States
Description:..1HP..1800RPM.145TC.TE.
Dimensions12.49 in L x 8.8 in W x.
Drive End Bearing Size6205
Drive End Bearing TypeBall
Duty CycleContinuous
Efficiency82.5, 82.5%
Efficiency %82.5 %
EnclosureTotally Enclosed Non-Ve.
Enclosure MaterialRolled Steel
Enclosure TypeTENV (Totally Enclosed .
Family SeriesLeeson Motors
Frame143TC
Frame MaterialRolled Steel
Frame RemarksFOOTLESS
Frequency60, 60 Hz
Frequency Rating60 Hz
Gross Weight0 lbs
Horsepower1 hp
HP1
Hz60
Insulation ClassClass F, F
Inverter DutyYes - Constant 1000:1
Item ConditionFACTORY NEW
Item Number122168.00
KW0.75
ManufacturerLEESON ELECTRIC CORPORA.
Manufacturer Part Number122168.00
MaterialRolled Steel
Maximum Ambient Tempera.40? C
MFG Part #:122168.00
Motor Shell Length8.66"
MountingRound
mountingC-face (NO base)
Mounting TypeC-Face, Round
NEMA Frame143TC
Net Weight0 lbs
Nominal Voltage240 VAC, 480 VAC
Number of Poles4
Number of Speeds1
Opp. Drive End Bearing .6203
Opp. Drive End Bearing .Ball
Overall Length12.49"
Phase3, 3 ph
Product TypeThree Phase
RotationReversible
RPM1760, 1,760 RPM, 1800
Service Factor1, 1.0
Shaft Diameter0.875, 0.875"
Shaft Length2.12", 2.12
Shaft Size0.875 in Dia x 2.12 in L
Ship Weight43 lbs.
Speed1760 rpm
Supplier:LEESON ELECTRIC CORPORA.
Temperature Rating40 deg C
Thermal ProtectionThermostat
UPC:691720993835
Voltage230/460
Voltage (AC)230 VAC, 460 VAC
Volts230/460

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomMRO Supply5768069125.371In StockLeeson125.37 @ 1
thumbzoomemotorpro.com122168.00131.01In StockLeeson43.0131.0 @ 1
kscdirect.comLEE 122168.00148.271In StockLEESON ELECTRIC CORPORATION148.27 @ 1
thumbzoomGalco122168.00-LEES156.231In StockLeeson156.23 @ 1
thumbzoomcbtcompany.com122168.00180.651In StockLeeson Electric180.65 @ 1
thumbzoomDealers Electric122168.00591.931In StockLeeson43.0591.93 @ 1
AmazonTPB078XPMHLP724.621In Stock10Leeson724.62 @ 1
thumbzoomZoroG2616771877.51In StockLeeson877.5 @ 1
