Leeson B583

B09HVBJPPK

LEESON B583 Farm Duty Motor,115/208-230V AC

LEESON B583 Farm Duty Motor,115/208-230V ACzoom

Attributes

Key Value
Amperage Rating4.8 to 4.5 A
Application TypeMilk Pump Duty Motor
Bearing TypeSealed Ball
Bolt Circle Dia.5 7/8 in
Capacitor RequiredYes
Country of Origin (subj.Mexico
Description:1,3450,TENV,56HCZ,1/60/.
Dimensions11.97 in L x 6.5 in W x.
Duty CycleContinuous
Enclosure TypeTotally Enclosed Not Ve.
FrameL56HCZ
Frequency Rating60 Hz
Full Load Amps4.8-4.5
Horsepower1 hp
HP1
Hz60
Ins. ClassB
Insulation ClassClass B
ItemPump Duty Motor
Item - Farm Duty MotorsMilk Pump Motor
Length Less Shaft10 1/32 in
ManufacturerLEESON ELECTRIC CORPORA.
MaterialRolled Steel
Max. Ambient Temp.104 Degrees F
MFG Part #:B583
Motor ApplicationFarm Duty
Motor BearingsBall
Motor DesignPermanent Split Capacit.
Motor Enclosure DesignTotally Enclosed Nonven.
Motor Frame MaterialRolled Steel
Motor Mounting TypeRigid Base
Motor Service Factor1
Motor Shaft DesignKeyed
Motor Shaft RotationCWSE
Motor Sub ApplicationPump
Motor Thermal ProtectionAuto
Mounting TypeRigid Base
Nameplate RPM3,450
No. of Speeds1
Overall Length11 31/32 in
PhaseSingle, 1 ph
RotationCW
RPM Range3,001-3,600
Service Factor1
Shaft Dia.5/8 in
Shaft Length1 15/16 in
Shaft Size0.625 in Dia x 1.94 in L
Special FeaturesPermanent Split Capacit.
Speed3450 rpm
StandardsCSA Certified, UL Recog.
Supplier:LEESON ELECTRIC CORPORA.
UPC:786674012517
Usable @ 200VNo
Usable @ 208VYes
Voltage208-230V AC
Voltage Compatibility115/208-230V AC, 200-23.
Weight37 lb

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomZoroG600722828405.691In Stock26Leeson37.0405.69 @ 1
kscdirect.comLEE B583483.441In StockLEESON ELECTRIC CORPORATION483.44 @ 1
