Littelfuse V10E320P

mpnV10E320PL1TX2855
brandname: Littelfuse Inc.
manufacturername: Littelfuse Inc.

LITTELFUSE INC. V10E320P Circuit Protection varistors-MOV-mlv UltraMOV Series ?10 mm 420 V 170 pF Radial Metal Oxide Varistor - 50 Item(s)

LITTELFUSE INC. V10E320P Circuit Protection varistors-MOV-mlv UltraMOV Series ?10 mm 420 V 170 pF Radial Metal Oxide Varistor - 50 Item(s)

zoom

Brand: Littelfuse
PartNumber: V10E320P
Model: V10E320P
PackageQuantity: 1
Manufacturer: LITTELFUSE
Label: LITTELFUSE

Attributes

Key	Value
Alternate Part No.	576-V10E320P
Approvals	UL
Brand	Littelfuse
Capacitance	170 pF
Capacitance @ Frequency	170 pF @ 1 MHz
Case Diameter	10 mm
Category	Circuit Protection
Clamping Voltage	840 V
Current - Surge	3.5 kA
Current Rating	25 A
Diameter	10 mm
Dimensions	10 mm Dia.
Energy	67J
Energy (Joules)	67 J
Energy E10/1000?s	67J
Family Series	Littelfuse Metal Oxide .
Gross Weight	0 lbs
Item Number	V10E320PL1TX2855
Manufacturer	Littelfuse
Manufacturer Part No.	V10E320P
Manufacturer Part Number	V10E320PL1TX2855
Max Applied Voltage DC	420 VDC
Max Applied Voltage RMS	320 Vrms
Max body dimensions	?10mm
Max Clamping Volts	840 V
Max. operating voltage	320V AC,
Maximum AC Volts	320 V
Maximum DC Volts	420 V
Mfr	Littelfuse Inc.
Mounting	THT, Radial
Mounting Type	Through Hole
Net Weight	0 lbs
Number of Circuits	1
Number of terminals	2
Operating Temperature	-55?C ~ 85?C (TA)
Operating temperature	-55...85?C
Operating Temperature R.	- 55 C to + 85 C
Package	Tape & Reel (TR)
Package / Case	Disc 10mm
Packaging	Bulk
Part Status	Active
Peak Current	3,500 A
Peak Surge Current	3.5 kA
Product	MOV
Product Category	Varistors
Product Series	LV UltraMOV
RoHS	Yes
Series	UltraMOV?
Surge Energy Rating	67 J
Termination Style	Radial
Type of varistor	metal-oxide
Varistor max current 8/.	3.5kA
Varistor voltage	510V
Varistor Voltage	459 V to 561 V
Varistor Voltage (Max)	561 V
Varistor Voltage (Min)	459 V
Varistor Voltage (Typ)	510 V
Voltage Rating AC	320 V
Voltage Rating DC	420 V

All Prices

Img	Seller	Supplier SKU	Min Price	MOQ	In Stock	Lead Time	Brand	Weight	Preferred Tier
	Digi-Key	3429363	0.247618	5000	50		Littelfuse Inc.		0.247618 @ 5000
	Galco	V10E320PL1TX2855-LF	0.26	5000	50		Littelfuse		0.26 @ 5000
	Newark	90T9559	0.275	5000	50		LITTELFUSE		0.275 @ 5000
	Hotenda	H613902	0.4164	1	50		Littelfuse		0.4164 @ 50
	swatee.com	V10E320P	1.15	1	459		Littelfuse		1.15 @ 50
	AmazonTP	B0748MFVL7	14.18	1	50	20	LITTELFUSE		14.18 @ 50
	AmazonSC	B0748MFVL7	21.9	1	50		Littelfuse		21.9 @ 50
	TME	V10E320P	115.62	5000	50		LITTELFUSE		115.62 @ 5000
