V26MLA0603H

B01MT8CONX

Varistors 26V 30A 45Pf

Varistors 26V 30A 45Pfzoom

Attributes

Key Value
Alternate Part No.576-V26MLA0603H
BrandLittelfuse
Capacitance110 pF
Capacitance @ Frequency110 pF @ 1 MHz
Case Code - in0603
Case Code - mm1608
Case Width0.8 mm
CategoryCircuit Protection
Clamping Voltage60 V
Current - Surge30 A
Dimensions0.8 mm W x 1.6 mm L x 1.
Energy0.10J
Energy (Joules)0.1 J
Family SeriesLittelfuse Metal Oxide .
Gross Weight0 lbs
Item NumberV26MLA0603H
ManufacturerLittelfuse
Manufacturer Part No.V26MLA0603H
Manufacturer Part NumberV26MLA0603H
Max Applied Voltage DC20 VDC
Max Applied Voltage RMS26 V
Max Clamping Volts60 V
Maximum AC Volts20 V
Maximum DC Volts26 V
MfrLittelfuse Inc.
MountingSMD/SMT
Mounting TypeSurface Mount, MLCV
Net Weight0 lbs
Number of Circuits1
Operating Temperature-55?C ~ 125?C (TA)
Operating Temperature R.- 55 C to + 125 C
PackageTape & Reel (TR)
Package / Case0603 (1608 Metric)
Package/Case0603 (1608 Metric)
PackagingReel
Peak Current3 A
Peak Surge Current30 A
ProductMLV
Product CategoryVaristors
Product SeriesMLA
Product StatusObsolete
RoHSYes
SeriesMLA
Surge Energy Rating0.1 J
Termination StyleSMD/SMT
Typical Capacitance (pf)11 pF
Varistor Voltage31 V
Varistor Voltage (Max)38 V
Varistor Voltage (Min)31 V
Varistor Voltage (Typ)34.5 V
Voltage26 VDC
Voltage Rating AC20 V
Voltage Rating DC26 V
Width0.8 mm

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
Future Electronics39103460.1908250050Littelfuse0.1908 @ 2500
HotendaH6136240.192215500Littelfuse0.1922 @ 50
thumbzoomGalcoV26MLA0603H-LF0.24250050Littelfuse0.24 @ 2500
thumbzoomswatee.comV26MLA0603H1.1413659Littelfuse1.14 @ 50
