- mpnTR-50526-05
- brandname: Macromatic
- manufacturername: Macromatic
Time Delay Relay,12VDC,10A,DPDT,0.1 sec.
- Brand: Macromatic
- PartNumber: TR-50526-05
- PackageQuantity: 1
- Binding: Misc.
- Manufacturer: Macromatic
- Label: Macromatic
Attributes
| Key | Value |
|---|
| AC Contact Rating - Rel. | 10 A @ 240V, 10A @ 240V |
| Adjustment Method - Tim. | Potentiometer |
| Adjustment Operator | Knob |
| Approvals | CE, CSA, cULus |
| Availability | In Stock, ships within . |
| Base Type - Plug In Rel. | Octal |
| Body Depth | 2.9 in |
| Body Depth - Relay | 1.70 in, 1.7 in |
| Body Height | 1.7 in |
| Body Height - Relay | 2.9 in, 2.90 in |
| Body Width | 2.3 in |
| Body Width - Relay | 2.40 in, 2.4 in |
| Brand | Macromatic |
| Coil Volts | 12V DC |
| Contact Form - Relay | DPDT |
| Contact Material | Silver Nickel |
| Contact Rating (A) | 10 A |
| Contacts | DPDT |
| Current Stock | 4 |
| DC Contact Rating - Rel. | 10A @ 30V, 10 A @ 30V |
| Electrical Connection | Socket |
| Family Series | Macromatic Relays, TR-5. |
| Flat Pin Width | Not Applicable |
| Function - Timing Relay | Interval On |
| Gross Weight | 0 lbs |
| Hz | 50/60 |
| Hz - Electrical | 50 Hz, 60 Hz |
| International Shipping | No |
| Item - Relay | Single Function Timing . |
| Item Number | TR-50526-05 |
| Manufacturer | Macromatic |
| Manufacturer Part Number | TR-50526-05 |
| Material | HAWA |
| Max Time | 10 s |
| Max. Time Setting - Tim. | 10 sec |
| Min. Time Setting - Tim. | 0.10 sec, 0.1 sec |
| Mode of Operation | Interval |
| Mounting - Relay | Plug In, Plug-In |
| Mounting Type | Socket |
| Mpn | TR-50526-05 |
| Multi-Function | No |
| Net Weight | 0 lbs |
| Nominal Coil Voltage | 12 VDC |
| Number of Pins - Relay | 8 |
| Overall Depth | 3.5 in |
| Overall Height - Relay | 3.10 in, 3.1 in |
| Power Consumption - Rel. | 2.0 W, 2 W |
| Primary Type | Time Delay Relays |
| Product Series | TR-5 |
| RoHS | Yes |
| Series | TR-5 Series |
| SKU | CU-333356433131 |
| Socket | 5X852, 1EGP3, 1EGP5 |
| Socket Code | A |
| Standards | UR, CSA, CE |
| Status Indicator | None |
| SubCategory | Electrical |
| Termination | 8 Pin |
| Time Range (Seconds) | 0-1, 0-2, 0-3, 0-5, 0-10 |
| Time Range Adjustment | Onboard |
| Timing Range | 0 |
| UPC | 801262045446 |
| Voltage (DC) | 12 VDC |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
 | Zoro | G8590242 | 28.99 | 1 | 7 | | Macromatic | 0.25 | 28.99 @ 1 |
| grainger.ca | WWG33VC11 | 41.5523935 | 1 | In Stock | | MACROMATIC | 0.25 | 41.5523935 @ 1 |
 | Raptor Supplies | AG3UEU | 54.258516 | 1 | In Stock | | MACROMATIC | | 54.258516 @ 1 |
| Grainger | 33VC11 | 54.75 | 1 | 1 | 0 | MACROMATIC | | 54.75 @ 1 |
 | sustainablesupply.com | C1190500 | 55.05 | 1 | In Stock | | Macromatic | 0.25 | 55.05 @ 1 |
 | simsupply.com | CU-333356433131 | 59.99 | 1 | In Stock | | Macromatic | | 59.99 @ 1 |
 | blackhawksupply.com | TR-50526-05 | 72.14 | 1 | In Stock | | Macromatic | | 72.14 @ 1 |
 | Walker Industrial | TR-50526-05 | 73.99 | 1 | In Stock | 17 | Macromatic | | 73.99 @ 1 |
 | Galco | TR-50526-05-MCRM | 81.6 | 1 | In Stock | | Macromatic | | 81.6 @ 1 |
| us.rs-online.com | 70882029 | 85.58 | 1 | In Stock | | Macromatic | | 85.58 @ 1 |
