Martin 80BTB11

B00452UPEU

Martin Roller Chain Sprocket, Taper Bushed, Type B Hub, Single Strand, 80 Chain Size, For 1215 Bushing, 1" Pitch, 11 Teeth, 1.25" Max Bore Dia., 4.006" OD, 2.4688" Hub Dia., 0.575" Width

Martin Roller Chain Sprocket, Taper Bushed, Type B Hub, Single Strand, 80 Chain Size, For 1215 Bushing, 1" Pitch, 11 Teeth, 1.25" Max Bore Dia., 4.006" OD, 2.4688" Hub Dia., 0.575" Widthzoom

Attributes

Key Value
Bore TypeTaper Bush
bore type:Bushed
bushing bore range:1/2 to 1-1/4 in
Bushing Size1215
bushing size:1215
bushing type:Taper Locking
caliper diameter:2.8884 in
chain / sprocket type:Standard Roller Chain
Chain Number80
chain number & pitch:80 / 1 in
Chain Pitch1 in
hardened teeth:Non-Hardened Teeth
hub diameter:2-15/32 in
length through bore:1.5000 in
manufacturer upc number:697950032122
MaterialSteel
material:Steel
number of hubs:1
number of strands acros.1
Number of Teeth11
Number Of Teeth11
number of teeth:11
Outside Dia4.006"
outside diameter:4.0060 in
overall width:1-1/2 in
Pitch1 in, 1.000 in.
pitch diameter:3.5495 in
pitch type:Single
Size1215
storage dimension heigh.1.5625 in
storage dimension lengt.4.1250 in
storage dimension width:4.1250 in
surface treatment:Protective Coating
tooth width:0.575 in
TypeBushed Roller Chain Spr.
weight:1.60 lbs

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomindustrialzone.com80BTB1157.314In StockMartin1.057.31 @ 4
us.rs-online.com7231954765.021In StockMartin Sprocket & Gear65.02 @ 1
cbtcompany.com80BTB1166.451In StockMartin Sprocket & Gear66.45 @ 1
thumbzoomMRO Supply26550967.481In StockMartin Sprocket67.48 @ 1
thumbzoommotionindustries.com0017370969.821In StockMartin69.82 @ 1
thumbzoomPurvis80BTB1170.241In StockMartin70.24 @ 1
thumbzoomAmazonSCB00452UPEU73.81In StockMartin73.8 @ 1
factorysupplyoutlet.comBS21QQ100.861In StockMARTIN100.86 @ 1
