mpn:
brand:
manufacturer:
MPN:
Weight:
0.33125
Weight:
0.33125 LB
Preferred Price:
221.0
Price:
221.0
Min Simple Price:
124.86
Absolute Min Price:
177.3
Min Price:
177.3
Dimensions:
[6.0, 5.0, 3.0]
qty:
21
simpleSku:
AzNTky:::B004BDO152
sku:
AzNTky::52:B004BDO152@y0
condition:
11
seller:
cbtcompany.com
amzMan:
martin
HazMat:
False
DropShip:
False
Attributes
| Key ^ | Value |
|---|---|
| Bore Diameter | 0.875 in ; 22.2 mm |
| Bore Type | Reboreable |
| Class | 6 |
| Country of Origin (subject to change) | United States |
| Diametral Pitch, Pitch | 10 |
| Enlarged OD With Special Tooth Form | NO |
| External Length | 0.875" (22.2mm) |
| Face Width (In.) | 1 |
| Gear Type, Hub Style, Style | B |
| Hub Dia. (In.) | 2.5 |
| Hub Outside Diameter | 2.5" (63.5mm) |
| Hub Projection (In.), Min. Bore | 0.875 |
| Key Way Size, Keyway, Set Screw Location, Set Screw Size | NONE |
| Length Through Bore | 1.875" (47.6mm) |
| Length through Bore, Storage Height | 1.875 |
| Material | Steel |
| Max. Bore | 1.5 |
| Maximum Bore Diameter | 1.5" (38.1mm) |
| Number of Teeth, Number Of Teeth | 45 |
| Outer Diameter | 4.7" (119.4mm) |
| Outside Dia | 4.700" |
| Outside Dia. (In.), Storage Length, Storage Width | 4.7 |
| Pitch Dia. (In.) | 4.5 |
| Pitch Diameter | 4.5" (114.3mm) |
| Pressure Angle | 14.5 Degrees PA |
| Pressure Angle (Deg.) | 14.5 |
| UPC Code | 697950056357 |
| Weight | 5.3 lbs. (2.4 kg), 5.3 |
| Width | 0 in |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
 | cbtcompany.com | S1045 | 124.86 | 124.86 | 1 | In Stock | Martin Sprocket & Gear | 124.86 @ Qty: 1+ | ||
| us.rs-online.com | 72332568 | 128.82 | 128.82 | 1 | In Stock | Martin Sprocket & Gear | 5.3 | 128.82 @ Qty: 1+ | ||
 | MRO Supply | 251132 | 136.77 | 136.77 | 1 | In Stock | Martin Sprocket | 136.77 @ Qty: 1+ | ||
 | industrialzone.com | S1045 | 144.0 | 201.6 | 2 | In Stock | Martin | 5.1 | 144.0 @ Qty: 2+ | |
 | apexindustrialautomation.com | S1045 | 148.67 | 148.67 | 1 | In Stock | Martin Sprocket | 148.67 @ Qty: 1+ | ||
 | Zoro | G3322710 | 155.86 | 155.86 | 1 | In Stock | Martin Sprocket & Gear | 5.3 | 155.86 @ Qty: 1+ | |
 | Purvis | S1045 | 167.48 | 167.48 | 1 | In Stock | Martin | 167.48 @ Qty: 1+ | ||
| motionindustries.com | 00372743 | 183.8 | 183.8 | 1 | In Stock | Martin | 183.8 @ Qty: 1+ |
