Martin S1048

B004BDO15C

Martin S1048 Spur Gear, 14.5? Pressure Angle, High Carbon Steel, Inch, 10 Pitch, 7/8" Bore, 5" OD, 1.000" Face Width, 48 Teeth

Martin S1048 Spur Gear, 14.5? Pressure Angle, High Carbon Steel, Inch, 10 Pitch, 7/8" Bore, 5" OD, 1.000" Face Width, 48 Teethzoom

Attributes

Key Value
Bore Diameter0.875 in ; 22.2 mm
Bore TypeReboreable
Class6
Diametral Pitch10
Enlarged OD With Specia.NO
External Length0.875" (22.2mm)
Face Width (In.)1
Gear TypeB
Hub Dia. (In.)2.5
Hub Outside Diameter2.5" (63.5mm)
Hub Projection (In.)0.875
Hub StyleB
Key Way SizeNONE
KeywayNONE
Length through Bore1.875
Length Through Bore1.875" (47.6mm)
MaterialSteel
Max. Bore1.5
Maximum Bore Diameter1.5" (38.1mm)
Min. Bore0.875
Number of Teeth48
Number Of Teeth48
Outer Diameter5" (127mm)
Outside Dia5.000"
Outside Dia. (In.)5
Pitch10
Pitch Dia. (In.)4.8
Pitch Diameter4.8" (121.9mm)
Pressure Angle14.5 Degrees PA
Pressure Angle (Deg.)14.5
Set Screw LocationNONE
Set Screw SizeNONE
Storage Height1.875
Storage Length5
Storage Width5
StyleB
UPC Code697950056371
Weight5.9 lbs. (2.7 kg), 5.9
Width0 in

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomindustrialzone.comS1048119.432In StockMartin1.0119.43 @ 2
us.rs-online.com72332569134.721In StockMartin Sprocket & Gear5.9134.72 @ 1
thumbzoomcbtcompany.comS1048137.41In StockMartin Sprocket & Gear137.4 @ 1
thumbzoomMRO Supply251133143.051In StockMartin Sprocket143.05 @ 1
thumbzoomPurvisS1048175.161In StockMartin175.16 @ 1
thumbzoomZoroG3325702182.631In Stock14Martin Sprocket & Gear5.9182.63 @ 1
motionindustries.com00372746192.231In StockMartin192.23 @ 1
