Martin D10CTB36

B00452UVRQ

Martin Roller Chain Sprocket, Taper Bushed, Type C Hub, Double Strand, 10B Chain Size, For 2517 Bushing, 15.88mm Pitch, 36 Teeth, 63.5mm Max Bore Dia., 190.98mm OD, 107.95mm Hub Dia., 25.55mm Width

Martin Roller Chain Sprocket, Taper Bushed, Type C Hub, Double Strand, 10B Chain Size, For 2517 Bushing, 15.88mm Pitch, 36 Teeth, 63.5mm Max Bore Dia., 190.98mm OD, 107.95mm Hub Dia., 25.55mm Widthzoom

Attributes

Key Value
Bore Dia. - Sprockets6.77107077854366
bore diameter:12.70 mm
Bore TypeBushed
bore type:Bushed
bushing bore range:1/2 to 2-1/2 in
Bushing Code2517
bushing size:2517
bushing type:Taper Lock Bushing
Caliper Diameter171.985197775009
caliper diameter:172.0 mm
chain / sprocket type:Metric Roller Chain
Chain Number10B-2
chain number & pitch:10B / 5/8 in
Chain Roller Dia.10.16
chain roller diameter:10 mm
chain roller width:10 mm
Country of Origin (subj.United States
Hardened TeethNo
hardened teeth:Non-Hardened Teeth
Hub Dia.107.95
Hub Dia. (In.)4.25
hub diameter:107.95 mm
hub outside diameter:108 mm
Hub Projection (In.)9.525
hub projection 2:10 mm
hub projection:10 mm
hub style:TB
hub type:C Hub
Length through Bore44.45
Length through Bore (In.1.75
length through bore:44.45 mm
manufacturer upc number:697950409948
MaterialSteel
material:Steel
Max. Bore57.15
maximum bore diameter:57.2 mm
Min. Bore12.7
number of hubs:2
Number of Rows2
number of strands acros.2
Number of Teeth36
number of teeth:36
Outside Dia.25.5524
Outside Dia. (In.)1.006
outside diameter:191.8 mm
overall width:44.45 mm
Pitch15.875
Pitch Dia.0.625
Pitch Dia. (In.)7.17107077854366
pitch diameter:182.1 mm
pitch type:Single
Roller Width9.65
Sprocket Hub TypeTB
storage dimension heigh.1.75 mm
storage dimension lengt.7.57 mm
storage dimension width:7.57 mm
Storage Height1.75
Storage Length7.57107077854366
Storage Width7.57107077854366
Surface TreatmentProtective Coating
surface treatment:Protective Coating
Tooth Thickness8.9662
tooth thickness:9 mm
tooth width:26 mm
TypeMetric Roller Chain
Weight9.319
weight:9.319 lbs
width across tooth sets:25.55 mm

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
AmazonB00452UVRQ140.131In StockMartin140.13 @ 1
thumbzoomindustrialzone.comD10CTB36183.792In StockMartin1.0183.79 @ 2
thumbzoomapexindustrialautomation.comD10CTB36222.141In StockMartin Sprocket222.14 @ 1
thumbzoommotionindustries.com02301397223.941In StockMartin223.94 @ 1
thumbzoomZoroG2443068301.01In Stock14Martin Sprocket & Gear9.319301.0 @ 1
thumbzoomMRO Supply256078333.791In StockMartin Sprocket333.79 @ 1
thumbzoomPurvisD10CTB36370.581In StockMartin370.58 @ 1
