Martin 35H80

B00452UELE

Martin Roller Chain Sprocket, Split Taper Bushed, Type B Hub, Single Strand, 35 Chain Size, For H Bushing, 0.375" Pitch, 80 Teeth, 1.5" Max Bore Dia., 9.77" OD, 2.5" Hub Dia., 1.25" Width

Martin Roller Chain Sprocket, Split Taper Bushed, Type B Hub, Single Strand, 35 Chain Size, For H Bushing, 0.375" Pitch, 80 Teeth, 1.5" Max Bore Dia., 9.77" OD, 2.5" Hub Dia., 1.25" Widthzoom

Attributes

Key Value
bore type:Bushed
bushing bore range:3/8 to 1-1/2 in
bushing size:H
bushing type:Split Taper
caliper diameter:9.3518 in
chain / sprocket type:Standard Roller Chain
chain number & pitch:35 / 3/8 in
hardened teeth:Non-Hardened Teeth
hub diameter:2-1/2 in
length through bore:0.8740 in
manufacturer upc number:697950103693
MaterialSteel
material:Steel
number of hubs:1
number of strands acros.1
Number Of Teeth80
number of teeth:80
Outside Dia9.769"
outside diameter:9.7690 in
overall width:1-1/2 in
Pitch0.375 in.
pitch diameter:9.5518 in
pitch type:Single
storage dimension heigh.0.8740 in
storage dimension lengt.9.7690 in
storage dimension width:9.7690 in
surface treatment:Protective Coating
tooth width:0.168 in
weight:3.61 lbs

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomindustrialzone.com35H80123.042In StockMartin1.0123.04 @ 2
thumbzoomMRO Supply261176135.751In StockMartin Sprocket135.75 @ 1
thumbzoomPurvis35H80150.641In StockMartin150.64 @ 1
thumbzoomZoroG3360370171.61In Stock14Martin Sprocket & Gear171.6 @ 1
thumbzoommotionindustries.com02167338178.441In StockMartin178.44 @ 1
factorysupplyoutlet.comWN20WW188.651In Stock25MARTIN188.65 @ 1
