- mpnPIC18F86K22-I/PTRSL
- brandname: Microchip Technology Inc.
- manufacturername: Microchip Technology Inc.
PIC18F86K22-I/PTRSL
- Brand: MICROCHIP
- PartNumber: PIC18F86K22-I/PTRSL
- Model: PIC18F86K22-I/PTRSL
- PackageQuantity: 1
- Manufacturer: Microchip Technology
- Label: Microchip Technology
Attributes
| Key | Value |
|---|
| A/D Bit Size | 12 bit |
| A/D Channels Available | 24 |
| ADC Channels | ADC Channels |
| ADC Resolution | 12bit |
| ADCs | 1(24 x 12 bit) |
| Alternate Part No. | 579-PIC18F86K22IPTRS |
| Base Product Number | PIC18F86K22 |
| Brand | Brand, Microchip Techno. |
| Category | Integrated Circuits (IC. |
| Connectivity | EBI/EMI, I?C, LINbus, S. |
| Core | PIC |
| Core Processor | PIC |
| Core Size | 8-Bit |
| Data Bus Width | 8 bit, 8bit |
| Data Converters | A/D 24x12b |
| Data RAM Size | 2 kB |
| Data RAM Type | SRAM |
| Data ROM Size | 1 kB |
| Data ROM Type | EEPROM |
| Device Core | Device Core |
| Dimensions | Dimensions |
| EEPROM Size | 1K x 8 |
| Family Name | Family Name |
| Height | Height |
| Instruction Set Archite. | Harvard |
| Interface Type | 3-wire, 4-wire, I2C, MS. |
| Length | Length |
| Manufacturer | Microchip |
| Manufacturer Part No. | PIC18F86K22-I/PTRSL |
| Maximum Clock Frequency | 64 MHz |
| Maximum Frequency | Maximum Frequency |
| Maximum Number of Ether. | 0 |
| Maximum Operating Tempe. | + 85 C, +85 ?C |
| Mfr | Microchip Technology |
| Minimum Operating Tempe. | - 40 C, Minimum Operati. |
| Mounting Style | SMD/SMT |
| Mounting Type | Surface Mount |
| Number of ADC Units | 1 |
| Number of CAN Channels | Number of CAN Channels |
| Number of Ethernet Chan. | Number of Ethernet Chan. |
| Number of I/O | 69 |
| Number of I/Os | 69 I/O |
| Number of I2C Channels | Number of I2C Channels |
| Number of LIN Channels | Number of LIN Channels |
| Number of PCI Channels | 0 |
| Number of PWM Units | 10 |
| Number of SPI Channels | Number of SPI Channels |
| Number of Timers | Number of Timers, 8 Tim. |
| Number of UART Channels | 2 |
| Number of USART Channels | Number of USART Channels |
| On-Chip ADC | Yes |
| On-Chip DAC | Without DAC |
| Operating Supply Voltage | 5.5 V |
| Operating Temperature | -40?C ~ 85?C (TA) |
| Oscillator Type | Internal |
| Package | Tray |
| Package / Case | 80-TQFP |
| Package Type | TQFP |
| Package/Case | TQFP-80 |
| Packaging | Tray |
| Peripherals | Brown-out Detect/Reset,. |
| Pin Count | Pin Count |
| Processor Series | PIC18 |
| Product Category | 8-bit Microcontrollers . |
| Product Status | Active |
| Program Memory Size | 64KB (32K x 16), 32 kB,. |
| Program Memory Type | FLASH, Program Memory T. |
| Pulse Width Modulation | 10 x 10 bit |
| PWM Resolution | 10bit |
| RAM Size | 4K x 8, RAM Size |
| Series | PIC? XLP? 18K, PIC18 |
| Speed | 64MHz |
| Stock | Stock |
| Supplier Device Package | 80-TQFP (12x12) |
| Supply Voltage - Max | 5.5 V |
| Supply Voltage - Min | 1.8 V |
| Timer Resolution | Timer Resolution |
| Timers | Timers |
| Typical Operating Suppl. | Typical Operating Suppl. |
| USB Channels | USB Channels |
| Voltage - Supply (Vcc/V. | 1.8V ~ 5.5V |
| Width | 12mm |
