Molex / Waldom 34696-0100

mpn34696-0100
brandname: Molex / Waldom
manufacturername: Molex / Waldom

Molex / Waldom 34696-0100 Connector Headers and PCB Receptacles

Molex / Waldom 34696-0100 Connector Headers and PCB Receptacles

zoom

Brand: Molex / Waldom
PartNumber: 34696-0100
PackageQuantity: 1
Manufacturer: Molex / Waldom
Label: Molex / Waldom

Attributes

Key	Value
Alternate Part No.	538-34696-0100
Brand	Molex
Category	Connectors, Interconnec.
Color	Black
Connector Type	Male Blade; Male Pin
Contact Finish - Mating	-
Contact Finish - Post	Copper Alloy
Contact Finish Thicknes.	Tin
Contact Finish Thicknes.	Automotive
Contact Length - Mating	0.110" (2.79mm)
Contact Length - Post	-
Contact Material	High Copper, Syndiotact.
Contact Plating	Nickel
Contact Shape	Tin
Contact Type	-
Current Rating	30 A
Current Rating (Amps)	500V
Fastening Type	-
Features	-40?C ~ 100?C
Housing Material	Thermoplastic
Ingress Protection	-
Insulation Color	-
Insulation Height	Rectangular, Square
Insulation Material	Board Guide
Manufacturer	Molex
Manufacturer Part No.	34696-0100
Mated Stacking Heights	-
Material Flammability R.	Black
Mfr	Molex
Mounting Angle	Right
Mounting Method	Wire to Board
Mounting Style	Through Hole
Mounting Type	Solder
Number of Positions	10, 2
Number of Positions Loa.	Board to Cable/Wire
Number of Rows	0.248" (6.30mm), 2
Operating Temperature	-
Operating Temperature R.	- 40 C to + 100 C
Overall Contact Length	0.868" (22.05mm)
Package	Active
Package Quantity	1
Packaging	Tray
Part # Aliases	0346960100
Part Status	Header
Pitch	1.5 mm, 2.8 mm
Pitch - Mating	10 (6 + 4 Power)
Product	Headers
Product Category	Automotive Connectors
Row Spacing - Mating	All
Series	Tray, 34696
Shrouding	Through Hole, Right Ang.
Style	Shrouded - 4 Wall
Termination	Latch Holder
Termination Style	Solder
Tradename	Stac64
Type	Polarization Option A
Voltage Rating	-, 500 V
