mpn:
brand:
manufacturer:
MPN:
Weight:
90.0
Weight:
90.0 LB
Preferred Price:
2756.33
Price:
2756.33
Min Simple Price:
1557.25
Absolute Min Price:
2211.29
Min Price:
2211.29
qty:
4
simpleSku:
zExNjM:::EDS-G512E-4GSFP
sku:
zExNjM::7L:EDS-G512E-4GSFP@y0
condition:
11
seller:
primebuy.com
amzMan:
moxa
HazMat:
False
DropShip:
True
Attributes
| Key ^ | Value |
|---|---|
| 100/1000BaseSFP Slots, Priority Queues, SFP/XFP Ports | 4 |
| Ambient Relative Humidity | 5 to 95% (non-condensing) |
| Buttons | Reset button |
| Category | Networking Solutions |
| Configuration | Fixed + SFP |
| Connection | 2 removable 4-contact terminal block(s) |
| Connector Type | RJ45 |
| Console Port | USB-serial console (Type B connector) |
| Copper Ports | 8 |
| Copper Type | 10/100/1000 |
| Description | 12-PORT MANAGED GBE SW |
| Detailed Description | Network Switch - Managed 12 Ports IP30 |
| Digi-Key Part Number | 3833-EDS-G512E-4GSFP-ND |
| Digital Input Channels | 1 |
| Dimensions | 79.2 x 135 x 137 mm (3.1 x 5.3 x 5.4 in) |
| DIP Switches | Turbo Ring, Master, Coupler, Reserve |
| EMI | FCC Part 15B Class A |
| Fiber Ports, Fiber Type | - |
| Freefall | IEC 60068-2-32 |
| Housing, Housing Material | Metal |
| IGMP Groups | 2048 |
| Ingress Protection, IP Rating | IP30 |
| Input Current | 0.34A @ 24 VDC, 0.34 A at 24 VDC |
| Input Voltage | 12/24/48/-48 VDC |
| Jumbo Frame Size | 9.6 KB |
| LED Indicators | PWR1, PWR2, STATE, FAULT, 10/100M (TP port), 1000M (TP port), 100/1000M (SFP port), MSTR/HEAD, CPLR/TAIL, smart PoE LED (EDS-G512E-8PoE-4GSFP Series only) |
| MAC Table Size | 8 K |
| Manufacturer Product Number | EDS-G512E-4GSFP |
| Manufacturer, Mfr | Moxa |
| Maximum Number of VLANs | 256 |
| Mounting Type | DIN Rail Mount, DIN Rail |
| Number of Ports | 12 |
| Operating Temperature | -10 to 60?C (14 to 140?F), -10?C ~ 60?C, 32 to 140 F (0 to 60 C) |
| Operating Voltage | 9.6 to 60 VDC |
| Overload Current Protection, Reverse Polarity Protection | Supported |
| Package | Box |
| Packet Buffer Size | 4 Mbits |
| Port Style | 8x 10/100/1000BaseT(X) ; 4x 100/1000BaseSFP |
| Power Substation | IEC 61850-3 ; IEEE 1613 |
| Product Status | Active |
| Railway | EN 50121-4 |
| Safety | UL 508 |
| Series | EDS-G512E Series, EDS-G512E |
| SFP/XFP Type | SFP, Gigabit |
| Shock | IEC 60068-2-27 |
| Special Features | Gigabit ; STP/RSTP/MSTP ;SMNPv3 ;HTTPS/SSH |
| Standards | Telcordia (Bellcore), GB |
| Storage Port | USB Type A |
| Storage Temperature (package included) | -40 to 85?C (-40 to 185?F) |
| Supply Voltage | 12 VDC ; 24 VDC ; 48 VDC |
| Time | 816,823 hrs |
| Traffic Control | NEMA TS2 |
| Type | Switch - Managed, Managed Switch |
| Vibration | IEC 60068-2-6 |
| VLAN ID Range | VID 1 to 4094 |
| Voltage - Input | -48V ~ 48V |
| Weight | 1,440 g (3.18 lb) |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
 | primebuy.com | EDS-G512E-4GSFP | 1557.25 | 1557.25 | 1 | In Stock | Moxa | 1440.0 | 1557.25 @ Qty: 1+ | |
| us.rs-online.com | 71988990 | 1806.0 | 1806.0 | 1 | 3 | Moxa | 1806.0 @ Qty: 1+ | |||
 | Zoro | G4414508 | 1869.99 | 1869.99 | 1 | In Stock | Moxa | 1869.99 @ Qty: 1+ | ||
 | Digi-Key | 15216241 | 1901.0 | 1901.0 | 1 | 4 | Moxa | 1901.0 @ Qty: 1+ |
