Nmb Technologies 09225SA-24M-EA-00

B073RQV19B

NMB TECHNOLOGIES 09225SA-24M-EA-00 92 x 25 mm 24 V 2750 RPM 45.2 CFM 29 db Ball Bearing DC Axial Fan - 2 item(s)

NMB TECHNOLOGIES 09225SA-24M-EA-00 92 x 25 mm 24 V 2750 RPM 45.2 CFM 29 db Ball Bearing DC Axial Fan - 2 item(s)zoom

Attributes

Key Value
Air Flow48.4 CFM (1.35m?/min)
Approval AgencyCE, UR, VDE
Base Product Number09225SA
Bearing TypeBall
CategoryFans, Thermal Management
Current Rating (Amps)0.070A
Fan TypeTubeaxial
Features-
Ingress Protection-
Lifetime @ Temp.100000 Hrs @ 25?C
Material - BladePlastic
Material - FramePlastic
MfrNMB Technologies Corpor.
Noise32.0dB
Operating Temperature14 ~ 158?F (-10 ~ 70?C)
PackageBulk
Part StatusActive, Not For New Des.
Power (Watts)1.56 W
RPM2750 RPM
Series09225SA
Size / DimensionSquare - 92mm L x 92mm H
Static Pressure0.154 in H2O (38.4 Pa)
Termination2 Wire Leads
Voltage - Rated24VDC
Voltage Range12 ~ 27.6VDC
Weight0.209 lb (94.8 g)
Width25.00mm

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
Digi-Key35944729.5455002NMB Technologies Corporation0.2099.545 @ 2
HotendaH19018719.5911068NMB Technologies Corp.9.59 @ 2
thumbzoomNewark43Y758510.52902NMB TECHNOLOGIES10.52 @ 50
