NTN Bearing 33206

mpn33206
brandname: NTN
manufacturername: NTN

NTN Bearing 33206 Tapered Roller Bearing Cone and Cup Set, Steel, 30 mm Bore, 62 mm OD, 25 mm Width

NTN Bearing 33206 Tapered Roller Bearing Cone and Cup Set, Steel, 30 mm Bore, 62 mm OD, 25 mm Width

zoom

Brand: NTN Bearing
PartNumber: 33206
Model: NTN 33206
PackageQuantity: 1
Binding: Misc.
Manufacturer: NTN
Label: NTN

Attributes

Key	Value
Bearing Industry Number	4T-33206
Bearing Type	Tapered roller bearing
Bore Dia. (mm)	30 mm
Bore Diameter	30 mm
Bore Type	Cylindrical
Brand	Ntn
Cone Width	0.768 in
Cone Width (mm)	19.5 mm
Country of Origin (subj.	Japan
Current Stock	3
Dynamic Load Capacity	65 kN
Dynamic Load Capacity (.	14,600 lb
Enclosure	Open
Flange Diameter	Not Applicable
Flange Thickness	Not Applicable
Flange Type	Not Applicable
Housing Fillet Radius	1 mm
International Shipping	No
Item	Tapered Roller Bearing .
Lead Time	Expected to ship in 1-2.
Lubrication Openings	None
Material	Case carburized steel
Maximum Temperature	120 Degrees C
Minimum Temperature	-40 Degrees C
Mpn	33206
Number of Rows	One
Outside Dia. (mm)	62 mm
Outside Diameter	62 mm
Overall Width	25 mm
Ring Material	Alloy Steel
Ring Material Grade	AISI 52100
Roller Material	Alloy Steel
Roller Material Grade	AISI 52100
Shaft Fillet Radius	1 mm
SKU	ZO-G0745309
Standards	ABMA
Static Load Capacity	77 kN
Static Load Capacity (L.	17,300 lb
SubCategory	Power Transmission
System of Measurement	Metric
Two Row Design	Not Applicable
UPC	4547359530629

All Prices

Img	Seller	Supplier SKU	Min Price	MOQ	In Stock	Lead Time	Brand	Weight	Preferred Tier
	Zoro	G0745309	38.39	1	In Stock		Ntn	0.8	38.39 @ 1
	simsupply.com	ZO-G0745309	55.07	1	3		Ntn		55.07 @ 1
	motionindustries.com	01447733	57.05	1	In Stock		NTN		57.05 @ 1
	MRO Supply	283454	133.99	2	In Stock		NTN Bearing		133.99 @ 2
