NTN SUCFB204CCFG1

B09QBKVT9N

SUCFB204CCFG1 - NTN - Corrosion Resistant - Factory New

SUCFB204CCFG1 - NTN - Corrosion Resistant - Factory Newzoom

Attributes

Key Value
ApplicationFood and Beverage
Back Side to Center Wid.15 mm
Bearing Housing Materia.Stainless Steel
Bearing Insert Material440C Stainless Steel
Bearing Insert TypeBall
Bearing Material Grade440C
Bolt Hole Center-to-Cen.38 7/64 in
Bolt SizeM10
Bore Dia.25/32 in
Bore Diameter20 mm
Bore TypeCylindrical
ClosureDouble Sealed
Country of Origin (subj.Multiple
Flange Thickness8 mm
Housing MaterialStainless Steel
Housing Material FinishUnfinished
Housing Material Grade440C
Housing TypeFlange Bracket
Included BearingSUC204
Item3 Bolt Flange Bearing
Lubricant MaterialFDA/USDA-H1 Solid Grease
Lubrication OpeningsOne Zirc Fitting
Maximum Speed5,900 RPM
Maximum Temperature120 Degrees C
Minimum Temperature-20 Degrees C
Mount Hole Center-to-Ce.38.1 mm
Mount Hole Center-to-Ce.38.1 mm
Mount Hole Size10 mm
Mounting Bolt SizeM10
Number of Mount Holes3
Overall Height1 27/32 in
Overall Length4 1/4 in
Overall Width2 1/2 in
Resistance PropertiesCorrosion Resistant
Rolling Element Rows1
Seal TypeContact
Series204
Shaft Locking TypeSet Screw
Static Radial Load Capa.6,800 N
System of MeasurementMetric

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomZoroG6581882185.271In StockNtn2.8185.27 @ 1
