NTN UCF209-111D1

B007RH9BFY

NTN UCF209-111D1 Light Duty Flange Bearing, 4 Bolts, Setscrew Lock, Regreasable, Contact and Flinger Seals, Cast Iron, 1-11/16" Bore, 4-9/64" Bolt Hole Spacing Width, 5-13/32" Height

NTN UCF209-111D1 Light Duty Flange Bearing, 4 Bolts, Setscrew Lock, Regreasable, Contact and Flinger Seals, Cast Iron, 1-11/16" Bore, 4-9/64" Bolt Hole Spacing Width, 5-13/32" Heightzoom

Attributes

Key Value
Back Side to Center Wid.0.866 in
Bearing Housing Materia.Cast Iron
Bearing Insert Material52100 Chrome Steel
Bearing Insert TypeBall
Bolt Hole Center-to-Cen.4 9/64 in
Bolt Size1/2 in
Bolt Spacing4.141 Inch | 105.181 Mi.
Bore1.688 Inch | 42.875 Mil.
Bore Dia.1 11/16 in
Bore Diameter1 11/16 in
BrandNTN
Cartridge Pilot Depth0 Inch | 0 Millimeter
Cartridge Pilot Diameter0 Inch | 0 Millimeter
CategoryFlange Block Bearings
Category - BDIFlange Block
Dynamic Load Capacity7,350 lb
EAN4547359502220
Expansion / Non-expansi.Non-expansion
FinishPainted
Global Part Number GPN552679
Harmonized Tariff Code8483.20.40.40
Housing Configuration1 Piece Solid
Housing MaterialCast Iron
Housing Style4 Bolt Square Flange Bl.
Inch - MetricInch
Inner Ring Width4.9 mm
Insert Part NumberUC209-111D1
Item4 Bolt Flange Bearing
Keyword StringFlanged
Length Thru Bore1.937 Inch | 49.2 Milli.
Locking TypeSet Screw
Long Description4 Bolt Square Flange Bl.
Manufacturer Item NumberUCF209-111D1
Manufacturer NameNTN
Minimum Buy QuantityN/A
Mount Hole Center-to-Ce.4 9/64 in
Mount Hole Center-to-Ce.4 9/64 in
Mount Hole Size0.63 in
Mounting Bolt Size5/8 in
Mounting Bolts1/2 Inch
Mounting MethodSet Screw
Nominal Bolt Circle Dia.5.8 Inch | 148 Millimet.
NounBearing
Number of Mounting Holes4
Other FeaturesSingle Row | Light Duty.
Overall Height2 1/16 in
Overall Length5 13/32 in
Overall Width5 13/32 in
Pilot ConfigurationNo Pilot
price$ 77.05 / each
Product Group - BDIM06110
RelubricatableYes
Rolling ElementBall Bearing
SealsSingle Lip Land Riding
SeriesStandard Duty
Shaft Locking TypeSet Screws
Static Load Capacity4,590 lb
titleUCF209-111D1
UNSPSC31171501
Weight / kgm2.23
Weight / Kilogram2.23
Weight / LBS4.9

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomindustrialzone.comUCF209-111D164.24In StockNTN1.064.2 @ 4
thumbzoomLily BearingUCF209-111D165.491In StockNTN4.90665.49 @ 1
thumbzoomZoroG091059476.291In StockNtn4.976.29 @ 1
thumbzoomBDI Express123246885.863070791In StockNTN4.90685.86307079 @ 1
motionindustries.com02135256130.81In StockNTN130.8 @ 1
thumbzoomRaptor SuppliesAE6FBY186.6644911In StockNTN186.664491 @ 1
thumbzoomMRO Supply270016313.881In StockNTN Bearing313.88 @ 1
