Fairchild FQA24N50

B0137M4NDW

FQA24N50 Original Pulled Fairchild MOSFET

FQA24N50 Original Pulled Fairchild MOSFETzoom

Attributes

Key Value
Alternate Part No.512-FQA24N50
Base Product NumberFQA2
BrandFairchild Semiconductor
CaseTO3P
CategoryDiscrete Semiconductor .
Channel ModeEnhancement
ConfigurationSingle
Current - Continuous Dr.24A (Tc)
Drain to Source Voltage.500 V
Drive Voltage (Max Rds .10V
Fall Time155 ns
FET Feature-
FET TypeN-Channel
Forward Transconductanc.22 S
Gate Charge (Qg) (Max) .120 nC @ 10 V
Id - Continuous Drain C.24 A
Input Capacitance (Ciss.4500 pF @ 25 V
ManufacturerFairchild Semiconductor
Manufacturer Part No.FQA24N50
Maximum Operating Tempe.+ 150 C
MfrFairchild Semiconductor
Minimum Operating Tempe.- 55 C
Minimum Order245
Mounting StyleThrough Hole
Mounting TypeThrough Hole
Operating Temperature-55?C ~ 150?C (TJ)
PackageBulk
Package / CaseTO-3P-3, SC-65-3
Package/CaseTO-3PN-3
PackagingTube
Part # AliasesFQA24N50_NL
Part StatusActive
Pd - Power Dissipation290 W
Power Dissipation (Max)290W (Tc)
Product CategoryMOSFET
Rds On (Max) @ Id, Vgs200mOhm @ 12A, 10V
Rds On - Drain-Source R.200 mOhms
Rise Time250 ns
SeriesQFET?, FQA24N50
SKU417144
Supplier Device PackageTO-3P
TechnologyMOSFET (Metal Oxide)
Transistor PolarityN-Channel
TypeTransistor
Typical Turn-Off Delay .200 ns
Unit Weight6.401 g
Vds - Drain-Source Brea.500 V
Vgs (Max)?30V
Vgs - Gate-Source Break.30 V
Vgs(th) (Max) @ Id5V @ 250?A

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
Avnet ExpressFQA24N502.2037450936Fairchild Semiconductor2.2037 @ 450
Digi-Key125925792.318888888891355Fairchild Semiconductor2.31888888889 @ 135
Newark23AC53112.34305ONSEMI2.34 @ 5
QuestFQA24N502.62515Fairchild Semiconductor2.625 @ 5
Rochester ElectronicsFQA24N502.64405Fairchild Semiconductor2.64 @ 40
Mouser512-FQA24N504.321497Fairchild Semiconductor4.32 @ 5
Future Electronics80649064.3922005ON Semiconductor4.392 @ 200
swatee.comFQA24N505.342453388Fairchild Semiconductor5.34 @ 245
Little DiodeFQA24N5017.8217325110Fairchild Semiconductor17.8217325 @ 5
