ON Semiconductor MC14077BCPG

mpnMC14077BCPG
brandname: ON Semiconductor
manufacturername: ON Semiconductor

MC14077BCPG

MC14077BCPG

zoom

Brand: ON Semiconductor
PartNumber: MC14077BCPG
PackageQuantity: 1
Manufacturer: ON Semiconductor
Label: ON Semiconductor

Attributes

Key	Value
Base Product Number	MC14077
Category	Integrated Circuits (IC.
Circuit Type	Low-Power Schottky
Current - Output High, .	8.8mA, 8.8mA
Current - Quiescent (Ma.	1 ?A
Dimensions	19.56 x 6.60 x 3.68 mm
Features	-
Function Type	4-Channels
Height	0.145" (3.68mm)
High Level Output Curre.	-2.4 mA
Input Type	CMOS
Length	0.77" (19.56mm)
Logic Family	MC140
Logic Function	XNOR (Exclusive NOR)
Logic Level - High	3.5V ~ 11V
Logic Level - Low	1.5V ~ 4V
Logic Type	CMOS, XNOR (Exclusive N.
Low Level Output Current	2.4 mA
Max Propagation Delay @.	110ns @ 15V, 50pF
Maximum Operating Tempe.	+125 ?C
Maximum Propagation Del.	350 ns
Mfr	onsemi
Minimum Operating Tempe.	-55 ?C
Mounting Type	Through Hole
Number of Circuits	Quad, 4
Number of Elements	4
Number of Inputs	2
Number of Pins	14
Operating Temperature	-55?C ~ 125?C
Operating Voltage Range	3 to 18 V
Package	Tube
Package / Case	14-DIP (0.300", 7.62mm)
Package Type	PDIP
Product Header	Quad Exclusive NOR Gate
Product Status	Obsolete
Propagation Delay Test .	50 pF
Series	4000B Series, 4000B
Supplier Device Package	14-PDIP
Supply Current	30 ?A
Supply Voltage	3 to 18 V
Temperature Operating R.	-55 to +125 ?C
Voltage - Supply	3V ~ 18V
Width	0.26" (6.6mm)

All Prices

Img	Seller	Supplier SKU	Min Price	MOQ	In Stock	Lead Time	Brand	Weight	Preferred Tier
	Newark	73AK4295	0.234	1790	427		ONSEMI		0.234 @ 1000
	Digi-Key	11540816	0.235485963818	1603	438		onsemi		0.235485963818 @ 1603
	us.rs-online.com	70099864	0.29	1	427		ON Semiconductor		0.29 @ 1
