- mpnOA825AP-22-2WB
- brandname: Orion (Knight Electronics, Inc.)
- manufacturername: Orion (Knight Electronics, Inc.)
Orion Fans OA825AP-22-2WB Fans & Blowers Fan 80x25 220VAC Ball Wire 18cfm
- PartNumber: OA825AP-22-2WB
- PackageQuantity: 1
- Manufacturer: Orion Fans
- Label: Orion Fans
Attributes
| Key | Value |
|---|
| Air Flow | 18 CFM, 18.0 CFM (0.504. |
| Approval Agency | cURus, TUV |
| Approvals | cUR, TUV, UR |
| Approximate Size | 3.2 x 3.2 in. ; 80 x 80. |
| Approximate Thickness | 1 in. ; 26 mm |
| Base Product Number | OA825AP |
| Bearing Type | Ball |
| Category | Fans, Thermal Management |
| Configuration | Square |
| Current Rating (Amps) | - |
| Dimensions | 3.2 x 3.2 x 1 . ; 80 x . |
| Family Series | Orion Fans, AC-FAN Seri. |
| Fan Speed | 2,300 RPM |
| Fan Type | Tubeaxial, AC |
| Features | - |
| Gross Weight | 0 lbs |
| Impeller Material | Plastic |
| Ingress Protection | - |
| Item Number | OA825AP-22-2WB |
| Lifetime @ Temp. | 60000 Hrs @ 40?C |
| Manufacturer | Orion |
| Manufacturer Part Number | OA825AP-22-2WB |
| Material | Diecast Aluminum |
| Material - Blade | Polybutylene Terephthal. |
| Material - Frame | Aluminum |
| Maximum Operating Tempe. | 80 C |
| Mfr | Orion Fans |
| Minimum Operating Tempe. | -20 C |
| Net Weight | 0.57 lbs |
| Noise | 18.0dB |
| Noise Level | 24 dB, 24 dBA |
| Nominal Depth | 25 mm |
| Nominal Height | 80 mm |
| Nominal Voltage | 240 VAC |
| Nominal Width | 80 mm |
| Operating Temp Range (F) | -4-176 ?F |
| Operating Temperature | -4 ~ 176?F (-20 ~ 80?C) |
| Operating Voltage | 230 VAC |
| Package | Box |
| Power (Watts) | 6.00W |
| Power Consumption | 6 W |
| Power Rating | 6 W |
| Product Series | AC-FAN |
| Product Status | Active |
| RoHS | Yes |
| Rotation | CW |
| RPM | 2300 RPM |
| Series | OA825, OA825 Series |
| Size | 3.2 x 1 (80 x 25) In. (. |
| Size / Dimension | Square - 80mm L x 80mm H |
| Speed | 2300 RPM |
| Static Pressure | 0.14 in H2O (34.9 Pa), . |
| Tachometer Output | No |
| Termination | Wire Leads, 2 Wire Leads |
| Type | Square |
| Voltage - Rated | 230VAC |
| Voltage Range | 160 ~ 260VAC |
| Voltage Rating | 230 V |
| Weight | 0.573 lb (259.91 g) |
| Width | 27.00mm |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
| Digi-Key | 2621005 | 17.04075 | 40 | In Stock | | Orion Fans | 0.573 | 17.04075 @ 40 |
 | jensentools.com | 10141427 | 20.0 | 1 | In Stock | | Orion Fans | | 20.0 @ 1 |
| us.rs-online.com | 70103342 | 21.18 | 1 | In Stock | | Orion Fans | | 21.18 @ 1 |
 | Galco | OA825AP-22-2WB-ORIN | 23.53 | 1 | In Stock | | Orion | 0.57 | 23.53 @ 1 |
 | Newark | 36AJ7445 | 24.0 | 1 | In Stock | | ORION FANS | | 24.0 @ 1 |
