Phoenix.. 1778043

B07MF5TG2R

1778043, Conn Terminal Block F 8 POS 5.08mm Screw RA Panel Mount 12A (5 Items)

1778043, Conn Terminal Block F 8 POS 5.08mm Screw RA Panel Mount 12A (5 Items)zoom

Attributes

Key Value
Alternate Manufacturer .MSTB 2 5/ 8-STF-5 08
AWG Range24 - 12
CategoryConnectors, Interconnec.
ColorGreen
Color FamilyGreen
Connection TypeScrew
Contact Material-
Contact Mating FinishTin
Contact Tail Length-
Country of OriginUS - United States
Current - IEC12A
Current - UL15 A
Current Rating12 A
DescriptionTERM BLOCK PLUG 8POS ST.
Detailed Description8 Position Terminal Blo.
Digi-Key Part Number277-5734-ND
ECCNEAR99
FeaturesMating Flange
Header Orientation-
Height11.1 mm
Housing MaterialPolyamide (PA), Nylon
Ingress Protection-
Insulating Material Gro.I
Insulation Height0.591" (15.00mm)
ManufacturerPhoenix Contact
Manufacturer Product Nu.1778043
Manufacturer Standard L.5 Weeks
Material Flammability R.UL94 V-0
Maximum Load Current12 A
MfrPhoenix Contact
Mounting TypeFree Hanging (In-Line)
No. of Positions8
Number of Levels1
Number of Positions8, 8 Position
Operating Temperature-
PackageBulk
Pitch0.200" (5.08mm), 5.08 mm
Pitch (Spacing)5.08 mm
Plug Wire Entry180?
Positions Per Level8
Product StatusActive
Rated Current12A
Rated Voltage320V
Screw SizeM3
Screw TypeM3
SeriesCOMBICON MSTB
Stripping Length7 mm
Termination StyleScrew - Rising Cage Cla.
Torque - Screw0.5-0.6 Nm (4.4-5.3 Lb-.
TypePlug, Female Sockets
Voltage - IEC630 V
Voltage - UL300 V
Width50.65 mm
Wire Gauge or Range - A.12-30 AWG
Wire Gauge or Range - m.0.2-2.5mm?
Wire Strip Length7mm

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
Onlinecomponents.com17780437.691In StockPhoenix Contact7.69 @ 1
us.rs-online.com710412057.9250In StockPhoenix Contact7.92 @ 50
HotendaH15403528.461In StockPhoenix Contact8.46 @ 1
thumbzoomCarlton Bates Company780373975128.52156PHOENIX CONTACT8.52 @ 1
thumbzoomDigi-Key3490349.681264Phoenix Contact9.68 @ 1
MRO Stop7530154699.711In StockPhoenix Contact9.71 @ 1
Airline HydraulicsPHOENIX 177804310.11In StockPhoenix Contact10.1 @ 1
Graybar2201610110.8081In StockPhoenix Contact10.808 @ 1
thumbzoomNewark69R982911.251233PHOENIX CONTACT11.25 @ 1
