- mpn1825323
- brandname: PHOENIX CONTACT
- manufacturername: PHOENIX CONTACT
Phoenix Contact/Qt===1/1825323 1825323 PCB Plug Screw 5.08mm 12AWG 320V 12A 3 Position Combicon Control Series
- Brand: Generic
- PartNumber: 1825323
- Manufacturer: PHOENIX CONTACT/singleunit
- Label: PHOENIX CONTACT/singleunit
Attributes
| Key | Value |
|---|
| Alternate Mfr Part Numb. | IC 2 5/ 3-STF-5 08 |
| Alternate Part No. | 651-1825323 |
| Approvals | CSA ; UL Recognized |
| Brand | Phoenix Contact |
| Category | Connectors, Interconnec. |
| Color | Green |
| Connection Method | Screw |
| Contact Material | - |
| Contact Mating Finish | Tin |
| Contact Plating | Tin |
| Contact Tail Length | - |
| Current - IEC | 12A |
| Current - UL | 10 A |
| Current Rating | 12 A |
| Features | Mating Flange |
| Flammability Rating | UL 94 V-0 |
| Header Orientation | - |
| Housing Material | Polyamide (PA), Nylon, . |
| Ingress Protection | - |
| Insulating Material Gro. | I |
| Insulation Height | 0.591" (15.00mm) |
| Manufacturer | Phoenix Contact |
| Manufacturer Part No. | 1825323 |
| Material Flammability R. | UL94 V-0 |
| Maximum Load Current | 12 A |
| Mfr | Phoenix Contact |
| Mounting Type | Free Hanging (In-Line) |
| Number of Contacts | 3 |
| Number of Levels | 1 |
| Number of Positions | 3 |
| Operating Temperature | - |
| Package | Bulk |
| Part # Aliases | IC_2,5/_3-STF-5,08 IC25. |
| Pitch | 0.200" (5.08mm), 5.08 mm |
| Plug Wire Entry | 180? |
| Positions Per Level | 3 |
| Primary Type | PCB |
| Product | Plugs - Inverted |
| Product Category | Pluggable Terminal Bloc. |
| Product Status | Active |
| Screw Size | M3 |
| Screw Type | M3 |
| Series | IC, COMBICON IC, Combic. |
| Stripping Length | 7 mm |
| Termination | Screw |
| Termination Style | Screw - Rising Cage Cla. |
| Torque - Screw | 0.5-0.6 Nm (4.4-5.3 Lb-. |
| Tradename | COMBICON Control |
| Type | Plug, Plug, Male Pins |
| Unit Weight | 137 g |
| UPC Code | 4017918049485 |
| Voltage - IEC | 630 V |
| Voltage - UL | 300 V |
| Voltage Rating | 250 V, 320 V |
| Wire Gauge or Range - A. | 12-30 AWG |
| Wire Gauge or Range - m. | 0.2-2.5mm? |
| Wire Gauge Range | 24-12 |
| Wire Size | 12 AWG |
| Wire Strip Length | 7mm |
| Wire Termination Type | Screw |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
| Onlinecomponents.com | 1825323 | 3.92 | 1 | 66 | | Phoenix Contact | | 3.92 @ 1 |
| Radwell | 1825323 | 3.93 | 50 | 25 | | PHOENIX CONTACT | | 3.93 @ 50 |
| Hotenda | H1541941 | 4.31 | 1 | 23 | | Phoenix Contact | | 4.31 @ 1 |
| MRO Stop | 753016866 | 4.96 | 1 | In Stock | | Phoenix Contact | | 4.96 @ 1 |
| RS Delivers | 176-1248 | 5.016 | 1 | 50 | | Phoenix Contact | | 5.016 @ 1 |
| us.rs-online.com | 71065150 | 5.13 | 50 | 100 | | Phoenix Contact | | 5.13 @ 50 |
| Airline Hydraulics | PHOENIX 1825323 | 5.16 | 1 | In Stock | | Phoenix Contact | | 5.16 @ 1 |
 | swatee.com | 1825323 | 6.16 | 1 | 43 | | Phoenix Contact | | 6.16 @ 1 |
 | Newark | 32AC7335 | 6.41 | 1 | In Stock | | PHOENIX CONTACT | | 6.41 @ 1 |
| Digi-Key | 2526578 | 6.45 | 1 | In Stock | | Phoenix Contact | | 6.45 @ 1 |
