Rexnord KA2215F

B00BJPULXG

Rexnord KA2215F Spherical Roller Pillow Block Bearing, 4-Bolt, Set Screw Locking Collar, Light Contact Seals, Non-Expansion Type, Cast Iron, 2-15/16" Shaft, 3-1/4" Base To Center, 8-1/8" Bolt Centers

Rexnord KA2215F Spherical Roller Pillow Block Bearing, 4-Bolt, Set Screw Locking Collar, Light Contact Seals, Non-Expansion Type, Cast Iron, 2-15/16" Shaft, 3-1/4" Base To Center, 8-1/8" Bolt Centerszoom

Attributes

Key Value
Actual Bolt Center to C.8.1 Inch | 206Millimeter
base to bore centerline:3.2500 in
Base to Center Height3.25 Inch | 82.55 Milli.
base width:3-3/4 in
bearing type:Spherical Roller
bolt center-to-center l.8-1/8 in
Bolt Spacing Maximum0 Inch | 0Millimeter
Bolt Spacing Minimum0 Inch | 0Millimeter
bore type:Round
BrandREXNORD
CategoryPillow Block Bearings
Expansion / Non-expansi.Non-expansion
expansion type:Non-Expansion Bearing (.
finish/coating:Powder Coated
Global Part Number GPN503282
Harmonized Tariff Code8483.20.40.80
Housing Configuration1 Piece Solid
housing construction:Solid Pillow Block
Housing MaterialCast Iron
housing material:Cast Iron
Housing Style4 Bolt Pillow Block
Inch - MetricInch
Insert Part Number2215U
Length Thru Bore4 Inch | 101.6 Millimet.
locking device:Concentric Collar
lubrication type:Lubrication Fitting
Manufacturer NameREXNORD
maximum rpm:1900 RPM
Mounting Bolts5/8 Inch
Mounting MethodConcentric Collar
mounting:Four-Bolt Base
Nominal Bolt Center to .8.1 Inch | 206.4 Millim.
Number of Mounting Holes4
Other FeaturesDouble Row | Normal Dut.
overall width:4 in
price$ 864.00 / each
radial dynamic load cap.46800 lb
radial static load capa.55700 lb
RelubricatableYes
seal type:Contact/Lip
SealsLight Contact
series:2000
standards met:ANSI/ABMA STD 9-1990
titleKA2215F
UNSPSC31171511
Weight / LBS26.8

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomLily BearingKA2215F734.41In StockREXNORD26.8734.4 @ 1
thumbzoomMRO Supply502625920.471In Stock14Rexnord26.8920.47 @ 1
thumbzoomRadwellKA2215F1300.01In StockREXNORD1300.0 @ 1
thumbzoommotionindustries.com005888621300.531In StockRexnord1300.53 @ 1
