| Axial Motion | 0.50 mm |
| B1 Shaft Penetration, B2 Shaft Penetration | 8.6 mm |
| Bore Dia. | 10 mm x 8 mm |
| Bore Tolerance | +0.020 mm / -0.000 mm |
| Country of Origin (subject to change) | Ireland |
| Dynamic Torque Non-Reversing | 1.95 Nm |
| Dynamic Torque Reversing | 1.30 Nm |
| Length, Overall Length | 26.00 mm |
| Material | Anodized Aluminum |
| Max. Angular Misalignment | 3 deg |
| Max. Parallel Misalignment (In.) | 0.25 mm |
| Max. RPM | 15000 RPM |
| Max. Temp. Range (F) | -110?F to 175?F (-78?C to 79?C) |
| Measurement Type | Metric |
| Moment of Inertia | 9.9 g.cm^2 |
| Number of Screws | 4 |
| Outside Dia. | 20 mm |
| Screw Finish | Bright |
| Screw Material | 18-8 300 Series Stainless Steel |
| Screw Seating Torque | 1.76 Nm |
| Set Screw Size | M4 |
| Style | Set Screw |
| Torsional Stiffness (Deg./In.-Lbs.) | 2.3 Nm/Deg |
| Weight | 0.0343 lbs |
