Ruland MWCL-12-F

B0063KFDPI

Ruland MWCL-12-F One-Piece Clamping Shaft Collar, Double Wide, Black Oxide Steel, Metric, 12mm Bore, 28mm OD, 24mm Width

Ruland MWCL-12-F One-Piece Clamping Shaft Collar, Double Wide, Black Oxide Steel, Metric, 12mm Bore, 28mm OD, 24mm Widthzoom

Attributes

Key Value
Base Product NumberMWCL
Bore (B1)12 mm
Bore Dia.12 mm
Bore Tolerance+0.050 mm / +0.012 mm
Bore Type - CollarsPlain Bore
CategoryHardware, Fasteners, Ac.
Clearance Dia.32 mm
Clearance Diameter (C) .32.0 mm
Collar StyleClamp
Country of OriginUSA
Country of Origin (subj.United States
Description12 MM STEEL SHAFT COLLAR
Digi-Key Part Number3188-MWCL-12-F-ND
Dimension TypeMetric
Finish SpecificationHot Process Black Oxide.
Forged Clamp ScrewM4
Hex Wrench Size3.0 mm
ItemShaft Collar
Item - Shaft CollarsShaft Collar
ManufacturerRuland Manufacturing
Manufacturer Product Nu.MWCL-12-F
MaterialBlack Oxide 1215 Lead F.
Material - CollarsBlack Oxide 1215 Lead F.
Material Specification1215 Carbon Steel Bar
MfrRuland Manufacturing
Moment of Inertia9.701 x 10
Note 1Performance ratings are.
Number of Pieces1
Number of Screws2 ea
Operating Temp. Range-40 Degrees to 350 Degr.
Outer Diameter (OD)28 mm
Outside Dia.28 mm
PackageBag
Product StatusActive
Recommended Shaft Toler.+0.000 mm / -0.013 mm
Screw FinishBlack Oxide
Screw Location (R)10.01 mm
Screw MaterialAlloy Steel
Screw SizeM4
Seating Torque4.6 Nm
Series-
Shaft Locking Type - Co.1 Piece Clamp
Small Bore (B2)12 mm
Specifications1.102" (28.00mm) Outer .
System of MeasurementMetric
Tariff Code8483.60.8000
Temperature-40?F to 350?F (-40?C t.
TypeShaft Collar
UNSPC31162811
UPC634529107041
UPC Code63452910704
Weight (lbs)0.183700
Width24 mm
Width (W)23.6 mm
Width Tolerance+0.076 mm / -0.254 mm

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomZoroG799622225.01In Stock10Ruland0.225.0 @ 1
thumbzoomRulandMWCL-12-F30.971In StockRuland0.183730.97 @ 1
RS Delivers700-691331.54811Ruland31.548 @ 1
thumbzoomDigi-Key1359379655.4515Ruland Manufacturing55.45 @ 1
us.rs-online.com7217740162.4215Ruland Manufacturing62.42 @ 1
thumbzoomRaptor SuppliesAF9WDG73.298161In StockRULAND MANUFACTURING73.29816 @ 1
motionindustries.com0343286593.721In StockRuland Manufacturing Co Inc93.72 @ 1
