| Axial Motion | 0.028 in |
| B1 Shaft Penetration, B2 Shaft Penetration | 0.378 in |
| Bore Dia. | 0.375 in x 0.375 in |
| Bore Tolerance | +0.001 in / -0.000 in |
| Country of Origin (subject to change) | Ireland |
| Dynamic Torque Non-Reversing | 27.4 lb-in |
| Dynamic Torque Reversing | 18.1 lb-in |
| Length, Overall Length | 1.016 in |
| Material | Anodized Aluminum |
| Max. Angular Misalignment | 3 deg |
| Max. Parallel Misalignment (In.) | 0.006 in |
| Max. RPM | 15000 RPM |
| Max. Temp. Range (F) | -110?F to 175?F (-78?C to 79?C) |
| Measurement Type | Inch |
| Moment of Inertia | 0.3414 lb-in^2 |
| Number of Screws | 4 |
| Outside Dia. | 0.984 in |
| Screw Finish | Bright |
| Screw Material | 18-8 300 Series Stainless Steel |
| Screw Seating Torque | 3.20 Nm |
| Set Screw Size | M5 |
| Style | Set Screw |
| Torsional Stiffness (Deg./In.-Lbs.) | 26.6 lb-in/Deg |
| Weight | 0.0552 lbs |
