- mpnA53PD PLY 626
- brandname: Schlage
- manufacturername: Schlage
Schlage A53PD PLY 626 A Ser Entrance Lock Ply 626
- Brand: SCHLAGE
- PartNumber: A53PD PLY 626
- Model: A53PD PLY 626
- PackageQuantity: 1
- Binding: Misc.
- Manufacturer: INGERSOLL RAND SECURITY TECHNOLOGY
- Label: INGERSOLL RAND SECURITY TECHNOLOGY
Attributes
| Key | Value |
|---|
| # of Keys | 2 |
| ADA Approved | False |
| ADA Compliant | No |
| Also known as | A53PDPLY626, 6S-A53PDPL. |
| ANSI Function | F109 |
| Application | Schools; Hospitals; Hot. |
| Assembled Depth (in.) | 1.88 |
| Assembled Height (in.) | 2.625 |
| Assembled Width (in.) | 3.63 |
| Backset | 2-3/8 Inch, 1 x 2-1/4 I. |
| Backset size (in.) | 2-3/8 in |
| Base Material | Brass, Bronze |
| Bolt Protection | 1/2 In. |
| Certifications and List. | No Certifications or Li. |
| Color Code | 626/US26D |
| Country Of Origin | Mexico |
| Cylinder Type | P-6 Pin Conventional (K. |
| Cylinder Type Used | Conventional |
| Deadbolt strike width (. | 1.75 |
| Design | Plymouth |
| Door Locks & Knobs Prod. | Keyed Handlesets |
| Door Thickness | 1 3/8" - 1 7/8" |
| Dust Box | Plastic |
| Electrical/Mechanical | Mechanical |
| Features | Cold-Rolled Steel, and . |
| Finish | Satin Chrome, 626/US26D |
| Finish Description | Satin Chrome |
| Finish Family | Satin Chrome |
| Fire Rated | 3 Hours {A} |
| For Use With | Wood or Steel Doors |
| Front Material | Steel |
| Front Size | 1" x 2-1/4" |
| Function | 53-Entrance, 53-Entranc. |
| Function Description | Pushing and turning but. |
| Function Family | Entry/Entrance/Office |
| Grade | Grade 2, ANSI/BHMA Grad. |
| Hand | Non-handed, Reversible |
| Handing | Reversible |
| Handle Type | Knob |
| Includes | Latch, Lock, Strike Pla. |
| Item | Grade 2 Cyl Knob Latchs. |
| Key Material | Nickel Silver |
| Key Type | Different |
| Keyblank Grouping | SCHL-C-6-1 |
| Keying Charges | CCAM |
| Keyway | Schlage C |
| Keyway Type | Schlage C |
| Knob Diameter | 2.1250 |
| Knob Material | Brass, Bronze |
| Knob style | PLY-Plymouth |
| Knob Style Family | Round Flat Knob |
| Knob/Lever Size | 2-1/8 Inch |
| Latch Backset Dim | 2-3/8 In. |
| Latch Bolt Material | Brass |
| Latch Corner | Square |
| Latch Number | 11-085 |
| Latch Throw | 1/2 Inch |
| Latch Type | Deadlatch |
| Lever/Knob Design | PLY - Plymouth |
| Limited Warranty | 3 Year Warranty |
| Location Type | Commercial, Residential |
| Lock Face Size | 2-1/4 In. x 1 In. |
| Lockset Finish | Satin Chrome |
| Lockset Fire Rating | 3 hr |
| Lockset Function | Entrance/Office |
| Lockset Grade | 2 |
| Lockset Handle Type | Knob |
| Lockset Performance Str. | Medium Duty |
| Manufacturer Parent | Allegion |
| Manufacturer Warranty | 24012b42-6e6b-4629-9dcf. |
| Mortise / Cylindrical | Cylindrical |
| Number of Keys | 2 |
| Pack Size | 1 |
| Package Qty | 1 |
| Pins | 6 |
| Product Projection | 2-5/16 Inch |
| Product Type | Cylindrical Lock |
| Projection | 2.3125 |
| Required Door Thickness | 1-3/8 in to 1-7/8 in |
| Required door thickness. | 1-3/8 in |
| Rose Diameter | 2-9/16 Inch |
| Rose/Escutcheon Design | PLY - Plymouth |
| Rose/Escutcheon Trim | Round Rose |
| Security/ANSI Grade | ANSI Grade 3 (Good) |
| Series | A, A Series Knob Locks |
| Special Marks | Conventional Cylinder |
| Standards | ANSI A156.2, Meets or E. |
| Strike | T-Strike, 1-1/8 Inch x . |
| Strike Height | 2-3/4 In. |
| Strike Lip | 1-1/8 Inch |
| Strike Number | 10-001 |
| Strike Size | 1-1/8" x 2-3/4" |
| Strike Type | T-Strike |
| Strike Width | 1-1/8 In. |
| Style | Plymouth |
| Sub-Series | CL_Cylindrical_Locks_sc. |
| Thickness | 1-3/4 In. |
| UL Listing | ANSI A156.2-2011, Serie. |
| Warranty | 3 Year Limited |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
 | NRI Industrial | D719105 | 109.65 | 1 | In Stock | | SCHLAGE | | 109.65 @ 1 |
 | jmac.com | A53PD PLY 626 | 165.0 | 1 | In Stock | | SCHLAGE | | 165.0 @ 1 |
 | thebuilderssupply.com | SCH_A53PDPLY626 | 170.1 | 1 | 16777778 | | Schlage | | 170.1 @ 1 |
| absupply.net | SCHLAGE A53PD PLY 626 | 183.87 | 1 | In Stock | | Schlage | | 183.87 @ 1 |
 | Zoro | G0590025 | 247.99 | 1 | In Stock | | Schlage | 1.7 | 247.99 @ 1 |
 | DK Hardware | A53PD PLY 626 | 248.06 | 1 | In Stock | | Schlage Commercial | | 248.06 @ 1 |
