Square D LA1KN13

B00CON7946

Square D La1Kn13 Contactor+Relay Aux

Square D La1Kn13 Contactor+Relay Auxzoom

Attributes

Key Value
[Ith] Conventional Free.10 A 50 ?C
[Ue] Rated Operational .690 V AC 25...400 Hz
[Ui] Rated Insulation V.690 V IEC 60947-5-1 || .
Ambient Air Temperature.-25-50 ?C
Ambient Air Temperature.-50-80 ?C
Amperage Rating10, 10:00 AM
Amps10 A
ApplicationTeSys K LC1K;TeSys K CA.
Auxiliary Contacts Oper.Instantaneous
BrandSchneider Electric
Catalog NumberLA1KN13
China Rohs RegulationPro-active China RoHS d.
Circularity ProfileN/A
ComponentAuxiliary Contact Block
Connectionscrew clamp terminals 1.
Connections - Terminalsscrew clamp terminals 1.
Contact Configuration1NO-3NC, 1 NO + 3 NC;In.
Contact Current Rating10 A
Contact FormNO ; 3NC
Contact Rating10 A 50 A Degrees C
Control Voltage600
Country of OriginIndonesia
Depth35 mm
Device Short NameLA1
Dimensions1.28 in W x 35 mm D x 1.
Environmental Character.NORMAL ENVIRONMENT
Environmental Conditions-58 to 176 deg F Storag.
Environmental DisclosureENVPEP2106022
Eu Rohs DirectiveCompliant
Family NameTeSys Family
FeaturesMercury Free, Toxic Hea.
For Use WithTeSys K LC1K, TeSys K C.
GTIN00785901898665, 0338911.
Height30 mm
Insulation Resistance> 10 MOhm
Ip Degree Of ProtectionIP20 conforming to IEC .
ItemContactor+Relay Aux Con.
Item TypeAuxiliary Contact Block
Made in USANo
ManufacturerSchneider Electric
Mercury FreeYes
Minimum Switching Curre.5 mA
Minimum Switching Volta.17 V
MountingFront, Clip
Mounting LocationFront
Mounting StyleFront Mount
Mounting typeFront Clip-On
Net Weight0.045 kg
Non Overlap Distance0.5 mm
Number of Contacts1NO-3NC, 4, 4
Number of NC Aux. Conta.3
Number of NO Aux. Conta.1
Operating Altitude6561.68 ft (2000 m)
Operating Temperature-25-50 A Degrees C, -13.
Package Quantity1
Permissible Short-Time .80 A 1 s || 60 A 500 ms.
Pole Contact Composition1 NO + 3 NC
Product CertificationsCB Scheme || CCC || UL .
Product NameTeSys K
Product Or Component Ty.Auxiliary Contact Block
Protective TreatmentTC IEC 60068
RangeTeSys
Range CompatibilityTeSys K LC1K || TeSys K.
Reach Free Of SvhcYes
Reach RegulationFree of Substances of V.
Rohs Exemption Informat.Yes
SeriesTeSys?, TeSys Micra Ser.
Special FeaturesNORMAL ENVIRONMENT
StandardIECEE CB Scheme;UL;CSA;.
StandardsBS 5424, IEC 60947, NF .
Starter ActionsInstantaneous
Starter Amperage10 Amp
Starter Auxiliary Conta.1 NO + 3 NC
Starter ModelLA1
Sub BrandTeSys K
Sub ComponentTeSys K Auxiliary Conta.
Suitable For Use WithTeSys? K Control Relay .
Sustainable Offer StatusGreen Premium product
Terminal TypeScrew Terminal
Tightening Torque1.3 N.m Philips No 2 ||.
Toxic Heavy Metal FreeYes
TypeInstantaneous, Instanta.
UPC785901898665
UPC Code785901898665
Voltage690V AC
Voltage Rating575, 575 VAC
Warranty18 months
Warranty DescriptionContractual Warranty:18.
WeeeThe product must be dis.
Width38 mm

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomNewark15B95889.241In StockSCHNEIDER ELECTRIC9.24 @ 1
thumbzoomTMELA1KN1313.13112SCHNEIDER ELECTRIC13.13 @ 1
thumbzoomstandardelectricsupply.com218851817.071In StockSquare D (Schneider Electric)17.07 @ 1
thumbzoomZoroG315645017.291In StockSchneider Electric0.0917.29 @ 1
thumbzoomgordonelectricsupply.comLA1KN1317.691In Stock10SQUARE D17.69 @ 1
rspsupply.comSCHNEIDER LA1KN1320.361In StockSchneider Electric20.36 @ 1
us.rs-online.com7037919820.4111Schneider Electric20.41 @ 1
RS Delivers279-632121.612118Schneider Electric21.612 @ 1
thumbzoomsustainablesupply.comC303923521.621In StockSchneider Electric0.0921.62 @ 1
thumbzoomcrescentelectric.com3683123.321In StockSchneider Electric23.32 @ 1
thumbzoomNational Supply Network6966423330.371In StockSchneider Electric30.37 @ 1
thumbzoommayerelectric.comSQDLA1KN1346.931In StockSCHNEIDER ELECTRIC0.09946.93 @ 1
