Schneider LC1K09008M7

B01KVG8PI6

NEW Schneider Contactor LC1K09008M7 LC1-K09008M7 4P 2N0+2NC 20A 220/230V AC Coil

NEW Schneider Contactor LC1K09008M7 LC1-K09008M7 4P 2N0+2NC 20A 220/230V AC Coilzoom

Attributes

Key Value
ApplicationResistive load
BrandSCHNEIDER ELECTRIC
Catalog NumberLC1K09008M7
Coil Power Rating4.5-4.5 VA 20 A Degrees.
Coil Voltage220...230 V AC 50/60 Hz.
ConnectionSCREW CLAMP TERMINALS 1.
Contact Configuration2 NO + 2 NC, 2NO-2NC
Contact Rating20 A 50 A Degrees C POW.
Contactor seriesTeSys K
Contacts configurationNC x2 + NO x2
Control voltage220V AC
Country of OriginFrance
Dimensions57 mm D
Enclosure TypeOpen
Frequency Rating50/60, 50/60 Hz
Height58mm
Insulation voltage690V
Item TypeContactor
Leadsscrew terminals
Made in USANo
ManufacturerSCHNEIDER ELECTRIC
Max. operating current9A
Mountingfor DIN rail mounting,,.
Mounting typePlate/Rail
Number of Poles4
Operating Cycles3600 CYC/H,, 3600, 3600.
Operating temperature-25...50?C
Operating Temperature-25 to 50, -25 to 50 de.
SeriesTeSys? K LC1K
Size57 MM
Special Features20 A AT
StandardBS 5424-IEC 60947-NF C .
Sub BrandTeSys K
Switching capacity4kW
Terminal TypeScrew Clamp, Screw/Clamp
TypeNon-Reversing
Type of contactor4-pole
UPC785901535836
Warranty DescriptionContractual Warranty:18.
Width45mm

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomTMELC1K09008M730.291In StockSCHNEIDER ELECTRIC30.29 @ 1
thumbzoomkempstoncontrols.co.ukLC1K09008M745.10741951In StockSchneider45.1074195 @ 1
thumbzoomstandardelectricsupply.com231865781.111In StockSquare D (Schneider Electric)81.11 @ 1
thumbzoomgordonelectricsupply.comLC1K09008M783.591In Stock10SQUARE D83.59 @ 1
thumbzoomcrescentelectric.com25230697.281In StockSchneider Electric97.28 @ 1
thumbzoomRadwellLC1K09008M7100.01In StockSCHNEIDER ELECTRIC TELEMECANIQUE100.0 @ 1
Newark20K1177114.011In StockSCHNEIDER ELECTRIC114.01 @ 1
