Schneider LC1K12004B7

B01KZ5RVNI

NEW Schneider Contactor LC1K12004B7 LC1-K12004B7 4P 4NO 20A 24V AC Coil

NEW Schneider Contactor LC1K12004B7 LC1-K12004B7 4P 4NO 20A 24V AC Coilzoom

Attributes

Key Value
[Icw] Rated Short-Time .115 A 50 ?C - 1 s power.
[Ith] Conventional Free.20 A 60 ?C power circui.
[Uc] Control Circuit Vo.24 V AC 50/60 Hz
[Uimp] Rated Impulse Wi.8 kV
Auxiliary Contact1 NO
Average Impedance3 mOhm - Ith 20 A 50 Hz.
California Proposition .Antimony oxide & Antimo.
China Rohs RegulationPro-active China RoHS d.
Circularity ProfileENVEOLI1503003EN
Connections - Terminalsscrew clamp terminals 1.
Contact Configuration4 NO
Contact Current Rating20 A
Contactor Applicationresistive load
Control Circuit TypeAC 50/60 Hz
Control Circuit Voltage.operational 0.8...1.15 .
Control Voltage24 V
Depth57 mm
Device Applicationcontrol
Device Short NameLC1K
Environmental DisclosureENVPEP1503003EN
Eu Rohs DirectiveCompliant
Flame RetardanceV1 conforming to UL 94 .
Heat Dissipation1.3-1.3 W
Height58 mm
Hold-In Power Consumpti.4.5-4.5 VA 20 ?C)
Inrush Power In Va30-30 VA 20 ?C)
Irms Rated Making Capac.144 A AC power circuit .
Maximum Operating Rate3600 cyc/h
Mechanical Durability10 Mcycles
Mechanical Robustnessshocks contactor closed.
Mercury FreeYes
Mounting TypePanel Mount
Number of Poles4
Operating Altitude6561.68 ft (2000 m) wit.
Operating Time10...20 ms coil de-ener.
Overvoltage CategoryIII
Pole Contact Composition4 NO
Poles Description4P
Product CertificationsCB Scheme || CCC || UL .
Product Or Component Ty.contactor
Protective TreatmentTC IEC 60068 || TC DIN .
RangeTeSys
Rated Breaking Capacity110 A 440 V IEC 60947 |.
Reach Free Of SvhcYes
Reach RegulationFree of Substances of V.
Rohs Exemption Informat.Yes
Safety Reliability LevelB10d = 1369863 cycles c.
SeriesTeSys Micra Series
StandardsEN/IEC 60947-4-1 || GB/.
Sustainable Offer StatusGreen Premium product
Toxic Heavy Metal FreeYes
Utilisation CategoryAC-1
Warranty18 months
WeeeThe product must be dis.
Width45 mm

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomTMELC1K12004B740.51111SCHNEIDER ELECTRIC40.51 @ 3
standardelectricsupply.com236251086.1313Schneider Electric86.13 @ 3
thumbzoommayerelectric.comSQDLC1K12004B794.2513SCHNEIDER ELECTRIC94.25 @ 3
thumbzoomRadwellLC1K12004B7100.013SCHNEIDER ELECTRIC TELEMECANIQUE100.0 @ 3
Newark79C9834121.0613SCHNEIDER ELECTRIC121.06 @ 3
us.rs-online.com71414760121.9713Schneider Electric121.97 @ 3
