SIEMENS B160

B00WRO42TC

Siemens Distribution And Controls - B160

Siemens Distribution And Controls - B160zoom

Attributes

Key Value
(1P) Single PolePole
1/2Width (in)
12Case Quantity
120/240VACVoltage (V)
2.5Length (in)
3Height (in)
60 AmpAmperage
60AAmp Rating
AC Voltage Rating120/240V AC
Amperage60A
Amps60 A
ApplicationElectrical Distribution
ApprovalUL Listed, CSA Certifie.
AWG 6-4 | 3 -2/0Wire Gauge
B160Stock Code
BOLT-ONBreaker Style
BrandSiemens
Catalog NumberB160
CategoryCircuit Breakers
Circuit Breaker ActuatorToggle
Circuit Breaker Mountin.Bolt On
Circuit Breaker TypeStandard
Continuous current / ra.60 A
Country of OriginMX
CSA, UL ListedUL Listed
Current Rating60 A
DC Voltage RatingNot Rated
Depth3 in
Depth [in]:3 in
Design of the overload .THERMAL-MAGNETIC
Design of the product:BL
DisplayB160 BREAKER 60A 1P 120.
For additional options .Notes
For Use WithSiemens P1 Panelboards
Frame Size125A/BL
Gtin783643263505
Height4 in
Height [in]:3.75 in
ItemMiniature Circuit Break.
Length3.75 in
Length (Straight Wirewa.3.75 in
ManufacturerSiemens Industry, Inc.,.
Max. AIR Rating10kA at 120/240V AC
Max. Wire Size2 AWG (Al), 4 AWG (Cu)
Min. Wire Size8 AWG
MountingBolt On
Mounting TypeBolt-On
MpnB160
Number of Poles1
Number Of Poles:1
OverloadThermal Magnetic
PhaseSingle
Poles1
SeriesBL, BL Series
SiemensBrand
Size of the circuit-bre.BL(125A)
Standard:ULLISTED/CSA/NOMCERTIFI.
StandardsUL Listed
Suitability for operati.ELECTRICALDISTRIBUTION
Supply voltage frequenc.TRUE
Terminal ConnectionLug
Type/Tipo BLFamily
UNSPSC39121601
Upc783643263505
UPC783643263505
Voltage120VAC
Voltage / between phase.120 V
Voltage Rating120 V
Width1 in
Width [in]:1 in

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
AmazonSCB005XH6S6U12.01In StockSiemens12.0 @ 1
steinerelectric.com9317714.321In StockSiemens14.32 @ 1
simplybreakers.comB16014.991In StockSiemens \/ ITE14.99 @ 1
thumbzoommostelectric.comB16015.8712Siemens15.87 @ 1
thumbzoomAllfusesB16016.69153Siemens16.69 @ 1
thumbzoomsuperbreakers.comB16016.721In StockSiemens16.72 @ 1
Dale-ElectricB16027.361In StockSiemens Industry, Inc.27.36 @ 1
thumbzoombulbspro.comB16028.371In StockSiemens28.37 @ 1
standardelectricsupply.com220630828.731In StockSiemens28.73 @ 1
thumbzoomindustrialzone.comB16040.085In StockSiemens0.3340.08 @ 5
thumbzoomZoroG328212443.291In StockSiemens0.343.29 @ 1
thumbzoomsustainablesupply.comC119256946.971In StockSiemens0.346.97 @ 1
AmazonTPB00CRKU7OU51.771In Stock5Siemens51.77 @ 1
kirbyrisk.com56085062.951In StockSiemens62.95 @ 1
thumbzoomturtle.comITE B16064.971In StockSiemens64.97 @ 1
thumbzoomcrescentelectric.com24190977.251In StockSiemens77.25 @ 1
us.rs-online.com7155412983.881In StockSiemens83.88 @ 1
