SKF 22318 EK

B007VHQM9S

SKF 22318 EK Spherical Radial Bearing, Tapered Bore, Steel Cage, Normal Clearance, 90mm Bore, 190mm OD, 64mm Width

SKF 22318 EK Spherical Radial Bearing, Tapered Bore, Steel Cage, Normal Clearance, 90mm Bore, 190mm OD, 64mm Widthzoom

Attributes

Key Value
Adapter Part NumberSNW118 H2318 HA2318 HE2.
ApplicationVibratory Applications,.
Bore3.543 Inch | 90 Millime.
Bore Dia. (In.)3.5433 in
Bore Dia. (mm)90 mm
Bore Diameter90 mm
Bore ProfileTapered
Bore TypeTapered 1:12
CageSheet metal
Cage DesignationTwo window-type cages m.
Cage MaterialSteel
Category - BDISpherical Roller Bearing
Dynamic Load Capacity (.123,600 lb
Dynamic Load Capacity (.550,000 N
EAN7316570114676
EnclosureOpen
Fillet Radius2.5 mm
Harmonized Tariff Code8482.30.00.80
I.D.3 5/9 in
Inch - MetricMetric
Internal ClearanceC0-Medium
ItemSpherical Roller Bearing
Keyword StringSpherical
Long DescriptionBearing, Spherical; 90M.
LubricationGrease
Manufacturer NameSKF
Manufacturer URLhttps://www.skf.com
MaterialBearing steel
Minimum Buy QuantityN/A
Minimum Temperature-20 Degrees F
Mounting MethodAdapter Mount
NounBearing
Number of Raceway Ring .Double Row
Number of Rows of Rolle.Double Row
O.D. (in)7 1/2
Outside Dia. (In.)7.4803 in
Outside Dia. (mm)190 mm
Outside Diameter7.48 Inch | 190 Millime.
Overall Width64 mm
Product Group - BDIB04311
RelubricatableYes
Roller MaterialAlloy Steel
Roller Material Grade100Cr6
Rolling ElementSpherical Roller Bearing
Static Load Capacity (L.137,000 lb
Static Load Capacity (N)610,000 N
Temp. Range (F)-20 Degrees to 390 Deg.
TypeOpen
UNSPSC31171510
Weight / Kilogram8.612
Weight / LBS18.7
Width2.52 Inch | 64 Millimet.
Width (In.)2.5197 in
Width (mm)64 mm
Withdrawal NutKM21
Withdrawal SleeveAHX2318 (Specify bore)

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
RS Delivers207-8534610.861In StockSKF610.86 @ 1
thumbzoomMisumi USA22318 EK653.541In Stock18SKF653.54 @ 1
thumbzoomMRO Supply321807681.961In StockSKF Bearing681.96 @ 1
thumbzoomBDI Express1415292712.373795271In StockSKF18.9464712.37379527 @ 1
Grainger49T597801.01In Stock15SKF801.0 @ 1
thumbzoomZoroG8393761980.991In StockSkf19.0980.99 @ 1
thumbzoomsustainablesupply.comC15721721012.951In StockSKF19.01012.95 @ 1
motionindustries.com000650651208.971In StockSKF1208.97 @ 1
