SKF 7205 BECBP

B007VGLI7A

SKF 7205 BECBP Light Series Angular Contact Ball Bearing, Universal Mounting, ABEC 1 Precision, 40? Contact Angle, Open, Plastic Cage, Normal Clearance, 25mm Bore, 52mm OD, 15mm Width, 10200.0 pounds Static Load Capacity, 15600.00 pounds Dynamic Load Capacity

SKF 7205 BECBP Light Series Angular Contact Ball Bearing, Universal Mounting, ABEC 1 Precision, 40? Contact Angle, Open, Plastic Cage, Normal Clearance, 25mm Bore, 52mm OD, 15mm Width, 10200.0 pounds Static Load Capacity, 15600.00 pounds Dynamic Load Capacityzoom

Attributes

Key Value
ABEC Rating3
ABEC Tolerance3
Bore0.984 Inch | 25 Millime.
Bore Dia.25 mm
Bore Diameter25 mm
Bore TypeCylindrical
Cage MaterialPolymer, PA66
Category - BDIAngular Contact Ball Be.
Closure TypeNone
Contact Angle40 Degree
Contact Angle (Degree)40
Dynamic Load Capacity (.3,510
Dynamic Load Capacity (.15,600
EAN7316577149718
EnclosureOpen
Flush GroundYes
Harmonized Tariff Code8482.10.50.28
Housing Fillet Radius0.6 mm
Inch - MetricMetric
Inner Diameter25 mm
Internal ClearanceCB
ItemAngular Contact Ball Be.
Keyword StringAngular Contact
Long Description25MM Bore; 52MM Outside.
LubricationMT47 Grease
Manufacturer Item Number7205 BECBP
Manufacturer NameSKF
Max. RPM17,000 RPM
Maximum Capacity / Fill.No
Minimum Buy QuantityN/A
Mounting ArrangementUniversal
NounBearing
Number of Bearings1 (Single)
Number of RowsSingle
Number of Rows of BallsSingle Row
Other FeaturesNormal Axial Internal C.
Outer Diameter52 mm
Outside Dia.52 mm
Outside Diameter52 mm, 2.047 Inch | 52 .
Overall Width15 mm
Precision ClassABEC 3 | ISO P6
Product Group - BDIB00308
Rolling ElementBall Bearing
Series7200 Series
Shaft Fillet Radius0.6 mm
Snap RingNo
Standard Preload (lbs.)27
Standard Preload (N)120
Static Load Capacity (L.2,290
Static Load Capacity (N)10,200
Static Load Rating10 kN
System of MeasurementMetric
Temp. Range (F)-40 Degrees to 212 Deg.
TypeSingle Row Explorer
UNSPSC31171531
UPC Code7316577149718
Weight / Kilogram0.133
Weight / LBS0.278
Width15 mm, 0.591 Inch | 15 .

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomBDI Express142130879.6276866213SKF0.292679.62768662 @ 1
factorysupplyoutlet.comRA42CO87.81In Stock25SKF87.8 @ 1
thumbzoomZoroG814282789.9511Skf0.3189.95 @ 1
thumbzoomAmazonB007VGLI7A97.591In StockSKF97.59 @ 1
us.rs-online.com73220746101.361In StockSKF Bearings101.36 @ 1
thumbzoomPurvis7205 BECBP107.041In StockSKF107.04 @ 1
thumbzoomsustainablesupply.comC1572901122.881In StockSKF0.31122.88 @ 1
motionindustries.com02197063135.141In StockSKF135.14 @ 1
thumbzoomNational Supply Network45668860135.661In StockSKF135.66 @ 1
thumbzoombscsource.com7205BECBP152.291In StockSKF152.29 @ 1
