SKF NU305ECJ

B006KSV0F0

SKF NU 305 ECJ Cylindrical Roller Bearing, Removable Inner Ring, Straight, High Capacity, Steel Cage, Metric, 25mm Bore, 62mm OD, 17mm Width, 12000rpm Maximum Rotational Speed, 8210lbf Static Load Capacity, 9040lbf Dynamic Load Capacity

SKF NU 305 ECJ Cylindrical Roller Bearing, Removable Inner Ring, Straight, High Capacity, Steel Cage, Metric, 25mm Bore, 62mm OD, 17mm Width, 12000rpm Maximum Rotational Speed, 8210lbf Static Load Capacity, 9040lbf Dynamic Load Capacityzoom

Attributes

Key Value
Bearing TypeCylindrical Roller Bear.
Bore0.984 Inch | 25 Millime.
Bore Dia.25 mm
Bore Diameter25 mm
Bore Diameter Tolerance+0/-0.010 mm
Bore ProfileStraight
Bore TypeCylindrical
BrandSKF
Cage MaterialSteel
CategoryCylindrical Roller Bear.
Category - BDICylindrical Roller Bear.
Current Stock2
Dynamic Load Rating46.49 kN
EAN7316577059963
Global Part Number GPN455740
Harmonized Tariff Code8482.50.00.00
Housing Fillet Radius1 mm
Inch - MetricMetric
Inner Diameter25 mm
Inner Ring Outside Dia..1.5 in
Inner Ring Outside Dia..38.1 mm
Inner Ring Outside Diam.50.241 mm
Internal ClearanceC0-Medium, CN
International ShippingNo
Long Description25MM Bore; Straight Bor.
Manufacturer Item NumberNU 305 ECJ
Manufacturer NameSKF
Marking Cover/SealNone
MaterialBearing Steel
Minimum Buy QuantityN/A
MpnNU 305 ECJ
NounBearing
Number of Raceway Ring .Single Row
Number of Rows of Rolle.Single Row
O.D. (in)2 4/9
Other FeaturesHigh Capacity | Plain I.
Outer Diameter62 mm
Outer Ring Inside Dia. .1.9961 in
Outer Ring Inside Dia. .50.7 mm
Outer Ring Inside Diame.50 mm
Outside Dia.62
Outside Dia. Tolerance+0/-.013mm
Outside Diameter2.441 Inch | 62 Millime.
Outside Diameter Tolera.+0/-0.013 mm
Overall Width17 mm
Precision ClassRBEC 1 | ISO P0
price$ 73.63 / each
Product Group - BDIB04144
ProfileComplete with Outer and.
RelubricatableYes
RetainerYes
Retaining Ring DiameterNot Applicable
Roller MaterialSteel
Rolling ElementCylindrical Roller Bear.
RPM15000 RPM
SeparableInner Ring - Both Sides
Series3 Series
Shaft Fillet Radius1 mm
Shoulder Height (In.)2.1654 in
Shoulder Height (mm)55 mm
SKUCU-343954373535
Snap RingNo
Special FeaturesHigh Radial Load Carryi.
Static Load Capacity (L.8,200 lb
Static Load Rating36.48 kN
SubCategoryPower Transmission
titleNU 305 ECJ
Tolerance+0/-.010mm
UNSPSC31171547
UPC Code7316577059963
Weight / kgm0.254
Weight / Kilogram0.254
Weight / LBS0.56
Width17 mm, 0.669 Inch | 17 .

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
AmazonB006KSV0F055.661In StockSKF55.66 @ 1
thumbzoomLily BearingNU 305 ECJ62.591In StockSKF0.558862.59 @ 1
thumbzoomBDI Express142055367.52307211In StockSKF0.558867.5230721 @ 1
thumbzoomMRO Supply31518270.411In StockSKF Bearing70.41 @ 1
factorysupplyoutlet.comFC20BX76.991In Stock25SKF76.99 @ 1
us.rs-online.com7323915488.881In StockSKF Bearings88.88 @ 1
thumbzoomMisumi USANU 305 ECJ95.461In Stock18SKF95.46 @ 1
thumbzoomZoroG805746396.151In StockSkf0.5696.15 @ 1
motionindustries.com00125908118.51In StockSKF118.5 @ 1
thumbzoombscsource.comNU305ECJ120.691In StockSKF120.69 @ 1
thumbzoomNational Supply Network43340900122.981In StockSKF122.98 @ 1
thumbzoomsimsupply.comCU-343954373535123.191In StockSkf123.19 @ 1
